System And Components
423-9075 LINES GP-OILType 1
Group No: 423-9075
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1421596 | 1 ANGLE | 1 | |
| 1759106 | 2 ELBOW AS | 2 | |
| 6V9001 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3196213 | 3 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3256994 | 4 CLIP (SLOT) | 5 | |
| 3256995 | 5 CLIP (TAB) | 5 | |
| 3706299 | 6 UNION AS | 4 | |
| 6V8730 | UNION (FACE SEAL) | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 3855780 | 7 ELBOW AS | 1 | |
| 2T2170 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4288657 | 8 HOSE AS | 1 | |
| 4288658 | 9 HOSE AS | 1 | |
| 4312157 | 10 HOSE & TUBE AS | 1 | |
| 4312158 | 11 HOSE & TUBE AS | 1 | |
| 4422447 | 12 TUBE AS-OIL | 1 | |
| 4318906 | 13 HOSE & TUBE AS | 1 | |
| 4318907 | 14 HOSE & TUBE AS | 1 | |
| 4322433 | 15 HOSE AS | 1 | |
| 4352784 | 16 HOSE & TUBE AS | 1 | |
| 4422448 | 17 HOSE & TUBE AS | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 2 | |
| 1653931 | 19 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 20 BOLT (3/8-16X1.25-IN) | 1 | |
| 0910081 | 21 SPACER (10.5X20X10-MM THK) | 1 | |
| 1653930 | 22 BOLT (3/8-16X1.625-IN) | 1 | |
| 1833399 | 23 CONNECTOR AS | 3 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 9S8752 | 24 NUT-FULL (3/8-16-THD) | 1 | |
| 2147568 | 25 SEAL-O-RING | 1 | |
| 2287089 | 26 SEAL-O-RING | 3 | |
| 2P4437 | 27 CLAMP | 4 | |
| 3050660 | 28 SPACER (10.5X15X15-MM THK) | 1 | |
| 3196224 | 29 ELBOW AS | 1 | |
| 6V9876 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218610 | 30 CONNECTOR AS | 1 | |
| 9X2297 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3537956 | 31 GROMMET | 9 | |
| 0L1143 | 32 BOLT (3/8-16X2.5-IN) | 1 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6V8774 | 34 TEE | 1 | |
| 6V9850 | 35 ELBOW | 1 | |
| 1653929 | 36 BOLT (3/8-16X1.5-IN) | 1 | |
| 7X0623 | 37 WASHER (10.5X21X2-MM THK) | 1 | |
| 5T6374 | 38 SPACER (11X20X40-MM THK) | 1 | |
| 7W9094 | 39 SPACER (11X20X9-MM THK) | 1 |
