System And Components
433-6490 LINES GP-FUEL INJECTIONAN ATTACHMENT
Group No: 433-6490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2815977 | 1 CONNECTOR AS | 4 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | 1A SEAL-O-RING | 1 | |
| 2385081 | 1B SEAL-O-RING | 1 | |
| 2815978 | 2 CONNECTOR AS | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 2287092 | 2A SEAL-O-RING | 1 | |
| 2385081 | 2B SEAL-O-RING | 1 | |
| 2968175 | 3 SPACER (13.5X28.0X41.13-MM THK) | 2 | |
| 3196220 | 4 ELBOW AS | 1 | |
| 6V9008 | ELBOW | 1 | |
| 2287093 | 4A SEAL-O-RING | 1 | |
| 2385084 | 4B SEAL-O-RING | 1 | |
| 3676028 | 5 ADAPTER AS | 1 | |
| 2287091 | 5A SEAL-O-RING | 1 | |
| 2385081 | 5B SEAL-O-RING | 1 | |
| 3676027 | ADAPTER | 1 | |
| 3717187 | 6 PLUG AS | 3 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3603683 | PLUG | 1 | |
| 3893709 | 7 PLUG AS | 2 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3985596 | 8 PLUG AS | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3985601 | 9 PLUG AS | 3 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 4178880 | 10 HOSE AS | 1 | |
| 4265269 | 11 VALVE GP-CHECK | 1 | |
| 2287092 | 11A SEAL-O-RING | 1 | |
| 2385083 | 11B SEAL-O-RING | 1 | |
| 4265268 | VALVE-CHECK | 1 | |
| 4351956 | 12 BRACKET AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 4390001 | 13 HOSE AS | 1 | |
| 4390002 | 14 HOSE AS | 1 | |
| 4391835 | 15 ADAPTER AS | 1 | |
| 4391834 | ADAPTER-CROSS | 1 | |
| 2287091 | 15A SEAL-O-RING | 1 | |
| 2385084 | 15B SEAL-O-RING | 1 | |
| 4391889 | 16 ELBOW AS | 1 | |
| 1292327 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4394548 | 17 VALVE GP-CHECK | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4394547 | VALVE-CHECK | 1 | |
| 4416052 | 18 HOSE AS | 1 | |
| 4599991 | 19 TUBE AS | 1 | |
| 1A2029 | 20 BOLT (3/8-16X1.125-IN) | 3 | |
| 1A5822 | 21 BOLT (1/2-13X2.75-IN) | 2 | |
| 2287090 | 22 SEAL-O-RING | 1 | |
| 2287091 | 23 SEAL-O-RING | 2 | |
| 3048037 | 24 CONNECTOR AS | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 2147566 | 24A SEAL-O-RING | 1 | |
| 2287089 | 24B SEAL-O-RING | 1 | |
| 3218648 | 25 CONNECTOR AS | 2 | |
| 2T2991 | CONNECTOR | 1 | |
| 2287092 | 25A SEAL-O-RING | 1 | |
| 2385083 | 25B SEAL-O-RING | 1 | |
| 3256994 | 26 CLIP (SLOT) | 1 | |
| 3256995 | 27 CLIP (TAB) | 1 | |
| 3328562 | 28 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3537952 | 29 GROMMET | 2 | |
| 3537956 | 30 GROMMET | 1 | |
| 5P8245 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V9838 | 33 TEE-SWIVEL | 1 | |
| 8T1897 | 34 CLIP (SLOT) | 2 | |
| 8T1898 | 35 CLIP (TAB) | 2 | |
| 9X6458 | 36 WASHER-HARD (10.2X22.5X3-MM THK) | 3 |
