System And Components
520-0136 LINES GP-FUEL INJECTIONS/N BZ3118-UP
Group No: 520-0136
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 8 | |
| 1081434 | GROMMET | 1 | |
| 2385080 | 2 SEAL-O-RING | 1 | |
| 2815977 | 3 CONNECTOR AS | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3196222 | 4 ELBOW AS | 1 | |
| 6V9200 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3328562 | 5 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3474438 | 6 TEE AS | 1 | |
| 6V9843 | TEE | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 3676028 | 7 ADAPTER AS | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3676027 | ADAPTER | 1 | |
| 3717187 | 8 PLUG AS | 3 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3603683 | PLUG | 1 | |
| 3893709 | 9 PLUG AS | 2 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3985601 | 10 PLUG AS | 2 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 4265269 | 11 VALVE GP-CHECK | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385083 | SEAL-O-RING | 1 | |
| 4265268 | VALVE-CHECK | 1 | |
| 4391889 | 12 ELBOW AS | 1 | |
| 1292327 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4866748 | 13 PLATE | 2 | |
| 2147568 | 14 SEAL-O-RING | 1 | |
| 4997636 | 15 VALVE AS-CHECK | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4997635 | VALVE-CHECK | 1 | |
| 9S4185 | 16 PLUG (3/4-16-THD) | 1 | |
| 5016567 | 17 UNION AS | 1 | |
| 6V8732 | UNION | 1 | |
| 2287091 | SEAL-O-RING | 2 | |
| 5099460 | 18 VALVE GP-CHECK | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 5099459 | VALVE-CHECK | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5108258 | 19 TUBE AS | 1 | |
| 5458562 | 21 TUBE AS-FUEL | 1 | |
| 5200138 | 22 HOSE AS | 1 | |
| 5200139 | 23 HOSE AS | 1 | |
| 5200140 | 24 HOSE AS | 1 | |
| 5458563 | 25 HOSE AS | 1 | |
| 5200142 | 26 HOSE AS | 1 | |
| 0S1619 | 27 BOLT (3/8-16X3-IN) | 1 | |
| 1149224 | 28 SPACER (11.13X19.05X47-MM THK) | 1 | |
| 2287091 | 30 SEAL-O-RING | 2 | |
| 3218648 | 32 CONNECTOR AS | 2 | |
| 2T2991 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3537954 | 33 GROMMET | 1 | |
| 3B1915 | 34 BOLT (3/8-16X1.375-IN) | 2 | |
| 5M2894 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T1889 | 36 CLIP (SLOT) | 1 | |
| 8T1890 | 37 CLIP (TAB) | 1 | |
| 8S9191 | 39 BOLT (3/8-16X4-IN) | 2 | |
| 9S4191 | 40 PLUG (9/16-18-THD) | 1 | |
| 5387440 | 41 ELBOW AS | 1 | |
| 2287091 | SEAL-O-RING | 2 | |
| 2385084 | SEAL-O-RING | 1 | |
| 5387439 | ELBOW | 1 | |
| 9X6458 | 42 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
