System And Components
446-6318 LINES GP-FUELS/N C931-UP
Group No: 446-6318
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3196228 | 1 ELBOW AS | 1 | |
| 6V8721 | ELBOW | 1 | |
| 2287090 | 1A SEAL-O-RING | 1 | |
| 2385081 | 1B SEAL-O-RING | 1 | |
| 3849217 | 2 TEE AS | 1 | |
| 6V8775 | TEE-FACE SEAL | 1 | |
| 2287090 | 2A SEAL-O-RING | 2 | |
| 2385080 | 2B SEAL-O-RING | 1 | |
| 3985596 | 3 PLUG AS | 2 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3985601 | 4 PLUG AS | 2 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 4215682 | 5 VALVE GP-CHECK | 2 | |
| 4620846 | 6 HOSE & TUBE AS | 1 | |
| 4671476 | 7 HOSE AS | 1 | |
| 4693207 | 8 HOSE & TUBE AS | 1 | |
| 4693206 | 9 HOSE & TUBE AS | 1 | |
| 3510283 | 10 VALVE AS-SHUTOFF (FUEL) | 2 | |
| 6V7238 | VALVE-SHUTOFF | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4491206 | 11 HOSE AS | 1 | |
| 4590581 | 12 TEE AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4590580 | TEE | 1 | |
| 2609219 | 13 CONNECTOR AS | 2 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | 13A SEAL-O-RING | 1 | |
| 2385081 | 13B SEAL-O-RING | 1 | |
| 3893703 | 14 TEE AS | 1 | |
| 1180911 | TEE-O-RING PORT | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196227 | 15 ELBOW AS | 1 | |
| 6V9851 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3445674 | 16 NUT (M8X1.25-THD) | 2 | |
| 3526505 | 17 ELBOW AS | 3 | |
| 8T5429 | ELBOW | 1 | |
| 2287090 | 17A SEAL-O-RING | 1 | |
| 2385082 | 17B SEAL-O-RING | 1 | |
| 3537957 | 18 GROMMET | 2 | |
| 5P4116 | 19 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 5P8939 | 20 GROMMET | 1 | |
| 6W5458 | 21 SPACER (0.406X0.75X0.5-IN THK) | 1 | |
| 8T1887 | 22 CLIP (SLOT) | 2 | |
| 8T1888 | 23 CLIP (TAB) | 2 | |
| 8T1889 | 24 CLIP (SLOT) | 1 | |
| 8T1890 | 25 CLIP (TAB) | 1 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 2 |
