System And Components
364-8420 GEARBOX GP-DRIVES/N NWJ1-UP
Group No: 364-8420
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3909006 | 1 BEARING | 2 | |
| 3909007 | 2 BEARING | 2 | |
| 3909009 | 3 SEAL-O-RING | 1 | |
| 3909011 | 4 SEAL-O-RING | 1 | |
| 3909012 | 5 SEAL-O-RING | 2 | |
| 3909014 | 6 CONNECTOR | 6 | |
| 3909015 | 7 CONNECTOR | 2 | |
| 3909017 | 8 SHIM (3.4-MM THK) | 1 | |
| 3909018 | 9 SHAFT-INPUT | 1 | |
| 3909019 | 10 ADAPTER-PUMP | 1 | |
| 3909021 | 11 COVER | 1 | |
| 3909022 | 12 ELBOW | 4 | |
| 3909023 | 13 COVER | 1 | |
| 3909024 | 14 PUMP-OIL | 1 | |
| 3909025 | 15 CONNECTOR | 1 | |
| 3909027 | 16 PLATE-END | 2 | |
| 3909028 | 17 COLLAR | 2 | |
| 3909029 | 18 SHIM (3.4-MM THK) | 1 | |
| 3909030 | 19 SHAFT-OUTPUT | 1 | |
| 3909031 | 20 COVER | 1 | |
| 3909034 | 21 ELBOW | 1 | |
| 3909035 | 22 FILTER (GEARBOX OIL) | 1 | |
| 3909037 | 23 BLOCK | 1 | |
| 3909038 | 24 TUBE | 1 | |
| 3909040 | 25 TUBE | 1 | |
| 3909041 | 26 TUBE | 1 | |
| 3909042 | 27 TUBE | 1 | |
| 3909043 | 28 TUBE | 1 | |
| 3909044 | 29 TUBE | 1 | |
| 3909045 | 30 TUBE | 1 | |
| 3909046 | 31 BREATHER (GEARBOX) | 1 | |
| 3909047 | 32 SEAL-O-RING | 1 | |
| 3909048 | 33 SCREEN | 1 | |
| 3909074 | 34 FLANGE | 1 | |
| 3921712 | 35 COUPLING | 2 | |
| 3937969 | 36 CAP-OIL (GEARBOX) | 1 | |
| 4334615 | 37 SCREW (M6X1X6-MM) | 1 | |
| 4439107 | 38 COLLAR | 2 | |
| 4439108 | 39 SEAL | 2 | |
| 4559782 | 40 CASE AS | 1 | |
| 3909032 | CASE | 1 | |
| 3909033 | COVER | 1 | |
| 4646791 | 41 GAUGE (GEARBOX) | 1 | |
| 4923331 | 42 CONNECTOR | 1 | |
| 4923332 | 43 VALVE-CHECK | 2 | |
| 4923333 | 44 SEAL-O-RING | 2 | |
| 4923334 | 45 BRACKET | 1 | |
| 5131332 | 46 SEAL | 2 | |
| 5214952 | 47 STUD (M8X1X6-MM) | 2 | |
| 5241125 | 48 CONNECTOR | 1 | |
| 5241126 | 49 ELBOW | 1 | |
| 5241127 | 50 CONNECTOR | 1 | |
| 5241128 | 51 TUBE | 1 | |
| 5241161 | 52 CONNECTOR | 1 | |
| 5241162 | 53 CONNECTOR | 1 | |
| 5241163 | 54 CONNECTOR | 2 | |
| 5241164 | 55 TUBE | 1 | |
| 5241165 | 56 TUBE | 1 | |
| 5241166 | 57 CONNECTOR | 2 | |
| 5242955 | 58 TEE | 1 | |
| 5242956 | 59 CONNECTOR | 1 | |
| 5242957 | 60 CONNECTOR | 1 | |
| 5243902 | 61 TUBE | 2 | |
| 5243903 | 62 NOZZLE | 2 | |
| 1117927 | 63 EYEBOLT | 2 | |
| 2089282 | 64 BOLT (M8X1.25X25-MM) | 4 | |
| 2089310 | 65 BOLT-FLANGE HEAD (M12X1.75X30-MM) | 6 | |
| 2089316 | 66 BOLT-FLANGE HEAD (M12X1.75X70-MM) | 4 | |
| 6V5215 | 67 BOLT (M8X1.25X16-MM) | 4 | |
| 6V9828 | 68 CAP (ORFS) | 1 | |
| 7X2563 | 69 BOLT (M20X2.5X60-MM) | 23 | |
| 8T4123 | 70 WASHER (22X35X3.5-MM THK) | 47 | |
| 8T4141 | 71 BOLT (M20X2.5X70-MM) | 2 | |
| 8T6381 | 72 BOLT (M20X2.5X120-MM) | 22 | |
| 9M1974 | 73 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 4338111 | KIT-ELEMENT (GEARBOX OIL) | 1 |
