System And Components
377-2435 MOUNTING GP-AFTERCOOLERS/N NWJ1-UP
Group No: 377-2435
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1718676 | 1 CONNECTOR AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 2025371 | SEAL | 1 | |
| 3664664 | CONNECTOR | 1 | |
| 3218675 | 2 CONNECTOR AS | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 5195853 | 3 GASKET | 2 | |
| 3586239 | 4 BRACKET AS | 1 | |
| 3621342 | 5 HOUSING-AFTERCOOLER (FRONT) | 1 | |
| 5258035 | 6 HOUSING-AFTERCOOLER (REAR) | 1 | |
| 3621344 | 7 SUPPORT | 2 | |
| 3621345 | 8 PLATE | 2 | |
| 3621357 | 9 HOSE AS | 1 | |
| 3855780 | 10 ELBOW AS | 1 | |
| 2T2170 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4711956 | 11 HOSE AS | 1 | |
| 4711957 | 12 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 0L2070 | 13 BOLT (3/8-16X2.25-IN) | 12 | |
| 0S1588 | 14 BOLT (3/8-16X1.25-IN) | 72 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 4 | |
| 1A2029 | 16 BOLT (3/8-16X1.125-IN) | 16 | |
| 2287092 | 17 SEAL-O-RING | 2 | |
| 2385080 | 18 SEAL-O-RING | 1 | |
| 3256994 | 19 CLIP (SLOT) | 3 | |
| 3256995 | 20 CLIP (TAB) | 3 | |
| 3537956 | 21 GROMMET | 3 | |
| 3B1915 | 22 BOLT (3/8-16X1.375-IN) | 12 | |
| 3537952 | 23 GROMMET | 2 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 5M6213 | 25 PLUG-PIPE (1/4-18-THD) | 2 | |
| 6V9877 | 26 ELBOW | 1 | |
| 8T1898 | 27 CLIP (TAB) | 2 | |
| 8T1897 | 28 CLIP (SLOT) | 2 | |
| 8M9124 | 29 WASHER (10X22.5X8-MM THK) | 2 | |
| 9S8752 | 30 NUT-FULL (3/8-16-THD) | 12 | |
| 9X6458 | 31 WASHER-HARD (10.2X22.5X3-MM THK) | 53 | |
| 1077954 | 32 SPACER (10.2X22X8-MM THK) | 62 |
