System And Components
551-1528 MOUNTING GP-JACKET WTR HEATERS/N NWJ1-UP
Group No: 551-1528
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1444613 | 1 ANGLE AS | 2 | |
| 5511526 | 2 HOSE AS | 1 | |
| 5511527 | 3 HOSE AS | 1 | |
| 0530558 | 4 CLIP | 1 | |
| 2B0941 | 5 SPACER (10.5X19X19-MM THK) | 2 | |
| 3445674 | 6 NUT (M8X1.25-THD) | 2 | |
| 5K9090 | 7 SEAL-O-RING | 1 | |
| 5P1076 | 8 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P7468 | 9 CLIP (SLOT) | 2 | |
| 5P7469 | 10 CLIP (TAB) | 2 | |
| 5P8444 | 11 GROMMET (37-MM ID) | 2 | |
| 6V8188 | 12 NUT (1/2-13-THD) | 2 | |
| 7X0326 | 13 BOLT (1/2-13X3-IN) | 1 | |
| 8C6875 | 14 CONNECTOR | 1 | |
| 8S5107 | 15 SPACER (0.622X0.84X2-IN THK) | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4195 | 17 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 19 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4835 | 20 BOLT (1/2-13X2-IN) | 2 | |
| 8T6869 | 21 BOLT (M8X1.25X60-MM) | 2 |
