539-0713 WIRING GP-ENGINES/N PYA1-UP

Group No: 539-0713

Part Number	Part Name	Qty
5N2126	1 CONNECTOR (THERMOCOUPLE)	16
1834274	2 BRACKET	1
2341644	3 CONTROL GP-ENGINE MONITORING (THERMOCOUPLE)	1
2391844	4 SPACER (14X25X70-MM)	1
2450522	5 BRACKET	1
2450523	6 BRACKET	2
2566453	7 SENSOR-TEMPERATURE (2-PIN)(ENGINE COOLANT)	1
2566453	7A SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, SECONDARY)	1
2566453	7B SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, PRIMARY)	1
2566453	7C SENSOR-TEMPERATURE (2-PIN)(ENGINE OIL BLOCK INLET)	1
2566453	7D SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, PRIMARY)	1
2613856	8 BRACKET AS	1
8C3334	RIVET-TUBULAR	2
2786469	9 GROMMET	7
2818666	10 THERMOWELL	2
3591828	11 BRACKET AS	1
3596013	12 BRACKET AS	1
3724759	13 BRACKET	2
3832990	14 SENSOR GP-TEMPERATURE (THERMOCOUPLE)	16
4849878	15 SENSOR GP-PRESSURE (COMPRESSOR INLET AIR, RH)	1
4849878	15A SENSOR GP-PRESSURE (COMPRESSOR INLET AIR, LH)	1
4849879	16 SENSOR GP-PRESSURE (TURBOCHARGER INLET, RH)	1
4849879	16A SENSOR GP-PRESSURE (TURBOCHARGER INLET, LH)	1
5358805	17 BRACKET AS	1
9F6445	NUT-WELD (1/4-20-THD)	4
5422340	18 STRAP-CABLE	64
5457948	19 WIRING GP-ENGINE	1
0L1143	20 BOLT (3/8-16X2.5-IN)	2
0L1351	21 BOLT (3/8-16X0.875-IN)	7
0L2070	22 BOLT (3/8-16X2.25-IN)	1
0S0509	23 BOLT (3/8-16X0.75-IN)	8
0S1588	24 BOLT (3/8-16X1.25-IN)	14
1653929	25 BOLT (3/8-16X1.5-IN)	2
0S1594	26 BOLT (3/8-16X1-IN)	14
0S1615	27 BOLT (1/4-20X0.75-IN)	4
0S1620	28 BOLT (1/2-13X0.75-IN)	2
0S1621	29 BOLT (1/2-13X1-IN)	3
0S1622	30 BOLT (1/2-13X2-IN)	2
1189901	31 SPACER (12X20X10-MM THK)	1
1224026	32 SPACER (13X25X25-MM THK)	2
1240289	33 CLIP	1
1325789	34 CLIP (LADDER)	3
1391398	35 CLIP (LOOP)	2
1751367	36 SPACER (8.8X16X10-MM THK)	3
1772215	37 STRAP-DUAL CLAMP	1
1984766	38 WASHER-HARD (11X25X10-MM THK)	1
1984767	39 WASHER-HARD (13.5X30X12-MM THK)	2
1A2029	40 BOLT (3/8-16X1.125-IN)	3
1A9579	41 BOLT (5/16-18X1.5-IN)	1
1B2886	42 BOLT (1/2-13X3.75-IN)	1
1B9575	43 BOLT (5/16-18X1.56-IN)	1
2123426	44 SENSOR GP-SPEED (MAGNETIC, RH)	1
2123426	44A SENSOR GP-SPEED (MAGNETIC, LH)	1
2147566	45 SEAL-O-RING	3
2159632	46 SPACER (12X20X20-MM THK)	3
2287100	47 SEAL-O-RING	1
2385080	48 SEAL-O-RING	4
2616847	49 ADAPTER	2
2659033	50 SENSOR GP-SPEED (CAMSHAFT POSITION)	1
2659033	50A SENSOR GP-SPEED (CRANKSHAFT POSITION)	1
2771873	51 CLIP (LADDER)	1
2856393	52 CLIP (LADDER)(LADDER)	15
2B2694	53 BOLT (5/16-18X2-IN)	3
2M3403	54 BOLT (3/8-16X3.63-IN)	4
3118802	55 SPACER (10.5X19X57-MM THK)	4
3513525	56 CLIP (LADDER)	1
3523964	57 CLIP (LADDER)	2
3523965	58 CLIP (LADDER)	2
3523966	59 CLIP (LADDER)	2
3523967	60 CLIP (LADDER)	2
3523968	61 CLIP (LADDER)	6
3523969	62 CLIP (LADDER)	5
3523970	63 CLIP (LADDER)	1
3579033	64 CLAMP	1
3E4352	65 WASHER-HARD (8.8X20.5X2.5-MM THK)	2
3K0360	66 SEAL-O-RING	1
4152431	67 SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, RH)	1
4152431	67A SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, LH)	1
4P7429	68 CLIP (LADDER)	2
4P7581	69 CLIP (LADDER)	7
4P8134	70 CLIP (LADDER)	6
5390729	71 WIRING GP-ENGINE	1
5390731	72 WIRING GP-ENGINE	1
5499204	73 HARNESS AS-ENGINE	1
5M2894	74 WASHER-HARD (10.2X18.5X2.5-MM THK)	50
5P0537	75 WASHER-HARD (7.2X14.5X2-MM THK)	4
5P8245	76 WASHER-HARD (13.5X25.5X3-MM THK)	6
6V1581	77 CLIP (SLOT)	3
6V1582	78 CLIP (TAB)	3
6V1612	79 BOLT (1/2-13X9.75-IN)	2
6V6609	80 SEAL-O-RING	3
7C4354	81 CLIP (SLOT)	1
7D1649	82 WASHER-HARD (13.5X32X5-MM THK)	2
7G5984	83 CLIP (TAB)	7
7G5985	84 CLIP (SLOT)	7
7W5938	85 SCREW-TAPPING (10-24X0.622-IN)	1
8T5360	86 WASHER (12X22.5X2.5-MM THK)	2
9M1974	87 WASHER-HARD (8.8X16X2-MM THK)	1
9M8406	88 CLIP (LOOP)	1
9S4185	89 PLUG (3/4-16-THD)	1
9S8752	90 NUT-FULL (3/8-16-THD)	5
9X6458	91 WASHER-HARD (10.2X22.5X3-MM THK)	12
