System And Components
539-0712 WIRING GP-SENSOR -ENGINES/N PYA1-UP
Group No: 539-0712
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6458 | 1 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 1834274 | 2 BRACKET | 1 | |
| 2123426 | 3 SENSOR GP-SPEED (MAGNETIC) | 1 | |
| 2450522 | 4 BRACKET | 1 | |
| 2450523 | 5 BRACKET | 2 | |
| 2566453 | 6 SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 2566453 | 6A SENSOR-TEMPERATURE (2-PIN)(AIR INLET, SECONDARY) | 1 | |
| 2566453 | 6B SENSOR-TEMPERATURE (2-PIN)(ENGINE COOLANT TEMPERATURE) | 1 | |
| 2566453 | 6C SENSOR-TEMPERATURE (2-PIN)(SEPARATE CIRCUIT AFTERCOOLER) | 1 | |
| 2566453 | 6D SENSOR-TEMPERATURE (2-PIN)(ENGINE OIL) | 1 | |
| 2613856 | 7 BRACKET AS | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 2616847 | 8 ADAPTER | 2 | |
| 2659033 | 9 SENSOR GP-SPEED (CAMSHAFT POSITION) | 1 | |
| 2659033 | 9A SENSOR GP-SPEED (CRANKSHAFT POSITION) | 1 | |
| 2786469 | 10 GROMMET | 7 | |
| 2818666 | 11 THERMOWELL | 2 | |
| 3591828 | 13 BRACKET AS | 1 | |
| 3724759 | 14 BRACKET | 2 | |
| 4849878 | 15 SENSOR GP-PRESSURE (ATMOSPHERIC PRESSURE) | 1 | |
| 4849878 | 15A SENSOR GP-PRESSURE (CRANKCASE PRESSURE) | 1 | |
| 4849879 | 16 SENSOR GP-PRESSURE (AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 4849879 | 16A SENSOR GP-PRESSURE (AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 5390725 | 17 WIRING GP-ENGINE (LH) | 1 | |
| 5390727 | 18 WIRING GP-ENGINE (RH) | 1 | |
| 5422340 | 19 STRAP-CABLE | 33 | |
| 5457796 | 20 SENSOR GP-TEMPERATURE (TURBOCHARGER INLET, LH) | 1 | |
| 5457796 | 20A SENSOR GP-TEMPERATURE (TURBOCHARGER INLET, RH) | 1 | |
| 5457948 | 21 WIRING GP-ENGINE | 1 | |
| 0L1143 | 22 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1351 | 23 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S0509 | 24 BOLT (3/8-16X0.75-IN) | 7 | |
| 1B2886 | 25 BOLT (1/2-13X3.75-IN) | 1 | |
| 0S1588 | 26 BOLT (3/8-16X1.25-IN) | 15 | |
| 1653929 | 28 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 29 BOLT (3/8-16X1-IN) | 14 | |
| 0S1620 | 30 BOLT (1/2-13X0.75-IN) | 2 | |
| 0S1621 | 31 BOLT (1/2-13X1-IN) | 1 | |
| 0S1622 | 32 BOLT (1/2-13X2-IN) | 2 | |
| 1224026 | 33 SPACER (13X25X25-MM THK) | 2 | |
| 1240289 | 34 CLIP | 1 | |
| 1325789 | 35 CLIP (LADDER) | 4 | |
| 1391398 | 36 CLIP (LOOP) | 2 | |
| 1751367 | 37 SPACER (8.8X16X10-MM THK) | 2 | |
| 1772215 | 38 STRAP-DUAL CLAMP | 1 | |
| 1984766 | 39 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 1984767 | 40 WASHER-HARD (13.5X30X12-MM THK) | 2 | |
| 1A2029 | 41 BOLT (3/8-16X1.125-IN) | 3 | |
| 1B9575 | 42 BOLT (5/16-18X1.56-IN) | 1 | |
| 2147566 | 43 SEAL-O-RING | 3 | |
| 2159632 | 44 SPACER (12X20X20-MM THK) | 3 | |
| 2287100 | 45 SEAL-O-RING | 2 | |
| 2385080 | 46 SEAL-O-RING | 4 | |
| 2B2694 | 47 BOLT (5/16-18X2-IN) | 2 | |
| 2M3403 | 48 BOLT (3/8-16X3.63-IN) | 4 | |
| 3118802 | 49 SPACER (10.5X19X57-MM THK) | 4 | |
| 3398937 | 50 CLIP (LOOP) | 1 | |
| 3505720 | 51 CLIP (LADDER) | 2 | |
| 3523964 | 52 CLIP (LADDER) | 1 | |
| 3523965 | 53 CLIP (LADDER) | 2 | |
| 3523966 | 54 CLIP (LADDER) | 2 | |
| 3523967 | 55 CLIP (LADDER) | 2 | |
| 3523968 | 56 CLIP (LADDER) | 3 | |
| 3E4352 | 57 WASHER-HARD (8.8X20.5X2.5-MM THK) | 3 | |
| 3K0360 | 58 SEAL-O-RING | 1 | |
| 4P7581 | 59 CLIP (LADDER) | 7 | |
| 4P8134 | 60 CLIP (LADDER) | 3 | |
| 5M2894 | 61 WASHER-HARD (10.2X18.5X2.5-MM THK) | 42 | |
| 5P8245 | 62 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V1581 | 63 CLIP (SLOT) | 3 | |
| 6V1582 | 64 CLIP (TAB) | 3 | |
| 6V1612 | 65 BOLT (1/2-13X9.75-IN) | 2 | |
| 6V6609 | 66 SEAL-O-RING | 3 | |
| 7C4354 | 67 CLIP | 1 | |
| 7D1649 | 68 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 7G5984 | 69 CLIP (TAB) | 7 | |
| 7G5985 | 70 CLIP (SLOT) | 7 | |
| 8T5360 | 72 WASHER (12X22.5X2.5-MM THK) | 2 | |
| 9M8406 | 73 CLIP (LOOP) | 1 | |
| 9S4185 | 74 PLUG (3/4-16-THD) | 1 | |
| 9S8752 | 75 NUT-FULL (3/8-16-THD) | 5 | |
| 0L2070 | 76 BOLT (3/8-16X2.25-IN) | 1 | |
| 2391844 | 77 SPACER (14X25X70-MM) | 1 | |
| 2771873 | 78 CLIP (LADDER) | 1 | |
| 5P8937 | COMPOUND-JOINT (THERMAL) |
