System And Components
455-8684 WIRING GP-ENGINEAN ATTACHMENT
Group No: 455-8684
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N2126 | 1 CONNECTOR (THERMOCOUPLE) | 12 | |
| 9X3495 | 2 CLIP AS | 1 | |
| 9X6772 | 3 STRAP-CABLE | 29 | |
| 1439607 | 4 STRAP-CABLE | 12 | |
| 2123426 | 5 SENSOR GP-SPEED (ENGINE) | 1 | |
| 2450522 | 6 BRACKET | 1 | |
| 2450523 | 7 BRACKET | 2 | |
| 2613856 | 8 BRACKET AS | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 2616847 | 9 ADAPTER | 2 | |
| 2659033 | 10 SENSOR GP-SPEED (CAMSHAFT POSITION) | 2 | |
| 2786469 | 11 GROMMET | 6 | |
| 2883783 | 12 SENSOR-TEMPERATURE (AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 2883783 | 12A SENSOR-TEMPERATURE (AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 2883783 | 12B SENSOR-TEMPERATURE (ENGINE OIL) | 1 | |
| 2883783 | 12C SENSOR-TEMPERATURE (SEPARATE CIRCUIT AFTERCOOLER) | 1 | |
| 2883783 | 12D SENSOR-TEMPERATURE (INLET AIR) | 1 | |
| 3496231 | 13 BRACKET | 2 | |
| 3497374 | 14 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3497374 | 14A SENSOR GP-PRESSURE (CRANKCASE) | 1 | |
| 3497377 | 15 SENSOR GP-PRESSURE (AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 3497377 | 15A SENSOR GP-PRESSURE (AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 3559605 | 16 ADAPTER | 2 | |
| 3579033 | 17 CLAMP | 1 | |
| 3596007 | 18 BRACKET AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 1 | |
| 3596013 | 19 BRACKET AS | 1 | |
| 3603693 | 20 PLUG (3/4-16-THD) | 1 | |
| 3647416 | 21 BRACKET | 1 | |
| 3647417 | 22 HARNESS AS-CEM | 1 | |
| 3664683 | 23 ADAPTER | 3 | |
| 3724759 | 24 BRACKET | 1 | |
| 3774632 | 25 BRACKET AS | 1 | |
| 3832990 | 26 SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 12 | |
| 3964585 | 27 MODULE AS-EXHAUST TEMPERATURE (DIGITAL) | 1 | |
| 3434631 | MODULE-EXHAUST TEMPERATURE (SCANNER) | 1 | |
| 4152431 | 28 SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, RH) | 1 | |
| 4152431 | 28A SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, LH) | 1 | |
| 4255669 | 29 BRACKET | 1 | |
| 4484827 | 30 BRACKET | 1 | |
| 4558686 | 31 WIRING GP-ENGINE (RAIL, LH) | 1 | |
| 4558690 | 32 WIRING GP-ENGINE (RAIL, RH) | 1 | |
| 0140582 | 33 CLIP | 2 | |
| 0L1143 | 34 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L1351 | 35 BOLT (3/8-16X0.875-IN) | 3 | |
| 0S0509 | 36 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1588 | 37 BOLT (3/8-16X1.25-IN) | 17 | |
| 0S1590 | 38 BOLT (3/8-16X2-IN) | 2 | |
| 1653929 | 39 BOLT (3/8-16X1.5-IN) | 5 | |
| 0S1594 | 40 BOLT (3/8-16X1-IN) | 13 | |
| 0S1608 | 41 BOLT (3/8-16X3.75-IN) | 1 | |
| 0S1615 | 42 BOLT (1/4-20X0.75-IN) | 1 | |
| 0S1620 | 43 BOLT (1/2-13X0.75-IN) | 1 | |
| 0S1621 | 44 BOLT (1/2-13X1-IN) | 1 | |
| 0T0102 | 45 BOLT (3/8-16X0.625-IN) | 1 | |
| 1046202 | 46 CLIP (LADDER) | 1 | |
| 1153071 | 47 CLIP AS-CONNECTING (6-PIN) | 2 | |
| 1240289 | 48 CLIP | 2 | |
| 1325789 | 49 CLIP (LADDER) | 3 | |
| 1336934 | 50 SPACER (11X20X25-MM THK) | 1 | |
| 1391398 | 51 CLIP (LOOP) | 2 | |
| 1751367 | 52 SPACER (8.8X16X10-MM THK) | 1 | |
| 1984766 | 53 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 1A9579 | 54 BOLT (5/16-18X1.5-IN) | 1 | |
| 2147566 | 55 SEAL-O-RING | 4 | |
| 2159632 | 56 SPACER (12X20X20-MM THK) | 3 | |
| 2190669 | 57 SEAL-O-RING | 2 | |
| 2287100 | 58 SEAL-O-RING | 5 | |
| 2287101 | 59 SEAL-O-RING | 4 | |
| 2385080 | 60 SEAL-O-RING | 2 | |
| 2771873 | 61 CLIP (LADDER) | 1 | |
| 2856393 | 62 CLIP (LADDER) | 12 | |
| 2B2694 | 63 BOLT (5/16-18X2-IN) | 1 | |
| 2M3403 | 64 BOLT (3/8-16X3.63-IN) | 4 | |
| 3118802 | 65 SPACER (10.5X19X57-MM THK) | 4 | |
| 3309739 | 66 ADAPTER | 2 | |
| 3523964 | 67 CLIP (LADDER) | 1 | |
| 3523967 | 68 CLIP (LADDER) | 2 | |
| 3523968 | 69 CLIP (LADDER) | 4 | |
| 3523969 | 70 CLIP (LADDER) | 1 | |
| 3535439 | 71 CONNECTOR | 2 | |
| 3E4352 | 72 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 4L9337 | 73 BOLT (3/8-16X1.5-IN) | 1 | |
| 4P7428 | 74 CLIP (LADDER) | 1 | |
| 4P7429 | 75 CLIP (LADDER) | 4 | |
| 4P7581 | 76 CLIP (LADDER) | 3 | |
| 4P8134 | 77 CLIP (LADDER) | 3 | |
| 5M2894 | 78 WASHER-HARD (10.2X18.5X2.5-MM THK) | 46 | |
| 5P0537 | 79 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 5P8245 | 80 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V1581 | 81 CLIP (SLOT) | 4 | |
| 6V1582 | 82 CLIP (TAB) | 4 | |
| 6V1612 | 83 BOLT (1/2-13X9.75-IN) | 2 | |
| 6V6609 | 84 SEAL-O-RING | 2 | |
| 6V7978 | 85 SCREW-MACHINE (10-32X0.375-IN) | 3 | |
| 7G5984 | 86 CLIP (TAB) | 6 | |
| 7G5985 | 87 CLIP (SLOT) | 6 | |
| 7W5938 | 88 SCREW-TAPPING (10-24X0.622-IN) | 1 | |
| 7X0288 | 89 BOLT (3/8-16X1.625-IN) | 1 | |
| 8F1434 | 90 LOCKWASHER | 3 | |
| 9M8406 | 91 CLIP (LOOP) | 2 | |
| 9S8752 | 92 NUT-FULL (3/8-16-THD) | 8 | |
| 9X6458 | 93 WASHER-HARD (10.2X22.5X3-MM THK) | 13 |
