563-9145 WIRING GP-MACHINES/N HRZ1-507

Group No: 563-9145

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	2
0341432	2 STRAP-CABLE	2
0910081	3 SPACER (10.5X20X10-MM THK)	1
1258534	4 PLATE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
1336934	5 SPACER (11X20X25-MM THK)	1
1369699	6 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
3203061	7 SENSOR GP-PRESSURE (FUEL)	1
3262882	8 PLATE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
4844856	9 CLIP (LOOP)	1
1305300	10 CLIP	5
1497738	11 CLIP (LOOP)	8
1S0994	12 CLIP (LOOP)	1
2006345	13 SADDLE-MOUNTING (DUAL SWIVEL)	2
2022762	14 CLIP (LOOP)	2
2042281	15 STRAP-CABLE	17
2287101	16 SEAL-O-RING	1
2597140	17 STUD-TAPERLOCK (M10X1.5X80-MM)	1
2636342	18 CLIP	2
3432387	19 CLIP (LOOP)	8
3445675	20 NUT (M10X1.5-THD)	2
3537954	21 GROMMET	25
3822001	22 SENSOR GP-LIQUID LEVEL (WATER IN FUEL)	1
3K6060	23 LOCKNUT (3/8-16-THD)	1
4767210	24 HARNESS AS-CHASSIS	1
4832517	25 CLIP (LOOP)	11
4D9517	26 CLIP	5
4L6454	27 BOLT (3/8-16X1-IN)	1
5561681	28 HARNESS AS-FRONT CHASSIS	1
5576268	29 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
8N0869	COVER-TERMINAL (RED)	1
1598049	CABLE (00-GA, RED)(1250-CM)
2084617	TERMINAL-RING (00-GA, 1/2-IN SCREW)	1
2761786	COVER-TERMINAL (RED)	1
5642651	30 HARNESS AS-PUMP	1
6V1889	31 CLIP (LOOP)	15
8C3121	32 BOLT (5/16-18X1.5-IN)	2
8S0948	33 CLIP	4
8T1889	34 CLIP (SLOT)	12
8T1890	35 CLIP (TAB)	12
8T4121	36 WASHER-HARD (11X21X2.5-MM THK)	25
8T4133	37 NUT (M10X1.5-THD)	1
8T4136	38 BOLT (M10X1.5X25-MM)	2
8T4137	39 BOLT (M10X1.5X20-MM)	4
8T4185	40 BOLT (M10X1.5X50-MM)	1
8T4186	41 BOLT (M10X1.5X40-MM)	12
8T4195	42 BOLT (M10X1.5X30-MM)	2
8T4196	43 BOLT (M10X1.5X35-MM)	1
8T4224	44 WASHER-HARD (8.8X16X2-MM THK)	2
8T4896	45 WASHER-HARD (10.2X18.5X2.5-MM THK)	2
