System And Components
464-5548 TANK GP-COOLANTS/N HNK1-UP; KMT1-UP; KEW1-UP
Group No: 464-5548
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X7958 | 1 CLAMP-HOSE | 2 | |
| 1279323 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1P4278 | 3 CLAMP-HOSE | 2 | |
| 3855778 | 4 CONNECTOR AS | 1 | |
| 8K0001 | SEAL-O-RING | 1 | |
| 3378766 | CONNECTOR | 1 | |
| 3510273 | 5 ELBOW AS | 1 | |
| 6V8245 | ELBOW | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 3696875 | 6 ELBOW AS | 1 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 6V7486 | CONNECTOR | 1 | |
| 3920795 | 7 ADAPTER AS | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 8K4739 | ADAPTER | 1 | |
| 3E6909 | 8 CLIP (LOOP) | 2 | |
| 4638579 | 9 TANK GP-COOLANT | 1 | |
| 4792171 | 10 BOLT AS | 5 | |
| 5404452 | 11 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 6K0806 | 12 STRAP-CABLE | 2 | |
| 7D7233 | 13 CLIP (LOOP) | 1 | |
| 7M8485 | 14 SEAL-O-RING | 1 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4182 | 18 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4195 | 19 BOLT (M10X1.5X30-MM) | 1 | |
| 9Y9236 | 20 GAUGE-SIGHT (COOLANT) | 1 | |
| 3718094 | 21 HOSE (120-CM) | ||
| 5P1465 | 22 HOSE (120-CM) | ||
| 0374838 | 23 CLAMP | 1 |
