System And Components
399-4621 LINES GP-AIR TANKS/N TR21-UP
Group No: 399-4621
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L0766 | 1 ELBOW | 1 | |
| 1L1722 | 2 CONNECTOR-PIPE | 2 | |
| 1L2782 | 3 TEE-PIPE | 1 | |
| 2F1336 | 4 FITTING-HEAD | 1 | |
| 3D7587 | 5 ELBOW | 1 | |
| 3R4825 | 6 VALVE GP-AIR CONTROL (AIR TANK DRAIN) | 2 | |
| 6B9664 | 7 VALVE-AIR RELIEF | 1 | |
| 7D6936 | 8 VALVE AS-CHECK | 1 | |
| 8D4765 | 9 REGULATOR | 1 | |
| 9X2398 | 10 ELBOW | 3 | |
| 0319746 | 11 ELBOW | 1 | |
| 0910081 | 12 SPACER (10.5X20X10-MM THK) | 2 | |
| 1159190 | 13 VALVE GP-RELAY (AIR STARTING MOTOR) | 1 | |
| 1778847 | KIT-SEAL (RELAY VALVE) | 1 | |
| 1722404 | 14 FILM-INSTRUCTION (AIR TANK WATER DRAIN) | 2 | |
| 3012185 | 15 PLATE | 2 | |
| 3196227 | 16 ELBOW AS | 1 | |
| 6V9851 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3512811 | 17 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 3855780 | 18 ELBOW AS | 1 | |
| 2T2170 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3893737 | 19 ELBOW AS | 1 | |
| 2T1922 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3920796 | 20 ELBOW AS | 1 | |
| 6V9849 | ELBOW | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4305512 | 21 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4318064 | 22 ADAPTER | 1 | |
| 4488766 | 23 AIR DRYER GP | 1 | |
| 4488982 | 24 ADAPTER AS | 1 | |
| 8C6868 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4488985 | 25 ELBOW AS | 1 | |
| 2T2305 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4495305 | 26 PLATE | 1 | |
| 4742617 | 27 TEE AS | 1 | |
| 6V9835 | TEE | 1 | |
| 2287088 | SEAL-O-RING | 2 | |
| 4796698 | 28 HOSE AS | 1 | |
| 4849640 | 29 FILTER AS-GREASE | 1 | |
| 5357683 | BODY-FILTER | 1 | |
| 5357684 | BOWL-FILTER | 1 | |
| 5357685 | FILTER AS | 1 | |
| 4977228 | 30 HOSE AS | 2 | |
| 4977230 | 31 HOSE AS | 2 | |
| 4977235 | 32 HOSE AS | 1 | |
| 4977236 | 33 HOSE AS | 1 | |
| 5000506 | 34 PLATE AS | 1 | |
| 5037465 | 35 ELBOW AS | 4 | |
| 2287089 | SEAL-O-RING | 1 | |
| 5117746 | ELBOW | 1 | |
| 5215556 | 36 VALVE AS (RELIEF) | 1 | |
| 4809716 | MANIFOLD | 1 | |
| 4822531 | VALVE AS | 1 | |
| 5334159 | 37 BOLT AS | 2 | |
| 5444847 | 38 ADAPTER | 1 | |
| 1095605 | 39 ADAPTER-PIPE | 1 | |
| 1358575 | 40 BOLT AS | 4 | |
| 1358578 | 41 BOLT AS | 2 | |
| 1364992 | 42 SPACER (11X20X40-MM THK) | 1 | |
| 1419481 | 43 STUD-TAPERLOCK (M12X1.75X45-MM) | 4 | |
| 1434299 | 44 GROMMET | 2 | |
| 1600980 | 45 BLOCK | 1 | |
| 1S0994 | 46 CLIP (LOOP) | 1 | |
| 2219576 | 47 VALVE GP-SOLENOID (24-VOLT)(AUTOLUBE ACTUATION) | 1 | |
| 2219576 | 47A VALVE GP-SOLENOID (24-VOLT)(AIR STARTING) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5D5569 | CONNECTOR | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 2219578 | KIT-VALVE | 1 | |
| 2233490 | 48 CLIP | 1 | |
| 2287088 | 49 SEAL-O-RING | 13 | |
| 2287090 | 50 SEAL-O-RING | 1 | |
| 2287092 | 51 SEAL-O-RING | 3 | |
| 2681605 | 52 ELBOW AS | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2721882 | 53 STUD-TAPERLOCK (M12X1.75X80-MM) | 2 | |
| 2815933 | 54 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2815979 | 55 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2N1931 | 56 ELBOW-PIPE | 2 | |
| 2P1279 | 57 LOCKNUT (9/16-18-THD) | 2 | |
| 3218615 | 58 ELBOW AS | 3 | |
| 7X7902 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 3293356 | 59 NUT (M12X1.75-THD) | 9 | |
| 3309763 | 60 CONNECTOR AS | 1 | |
| 8C6872 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3445675 | 61 NUT (M10X1.5-THD) | 5 | |
| 3B6552 | 62 ELBOW-PIPE | 2 | |
| 3B7729 | 63 ELBOW | 1 | |
| 3F9559 | 64 LOCKWASHER | 4 | |
| 3J5390 | 65 PLUG (3/8-18-THD) | 1 | |
| 3P1823 | 66 ADAPTER-PIPE | 1 | |
| 4293165 | 67 HOSE AS | 1 | |
| 4293169 | 68 HOSE AS | 1 | |
| 4792171 | 69 BOLT AS | 26 | |
| 4792172 | 70 BOLT AS | 9 | |
| 4977229 | 71 HOSE AS | 1 | |
| 4977231 | 72 HOSE AS | 1 | |
| 4977232 | 73 HOSE AS | 1 | |
| 4977234 | 74 HOSE AS | 1 | |
| 4D0124 | 75 ELBOW | 1 | |
| 4K8864 | 76 CLIP (LOOP) | 17 | |
| 4M5281 | 77 BOLT (1/4-20X0.75-IN) | 2 | |
| 5887128 | 78 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 5895247 | 79 PUMP GP-LUBRICATION | 1 | |
| 5895783 | 80 HOSE AS | 1 | |
| 5895784 | 81 HOSE AS | 1 | |
| 5895785 | 82 HOSE AS | 1 | |
| 5895786 | 83 HOSE AS | 1 | |
| 5895787 | 84 HOSE AS | 1 | |
| 5895788 | 85 HOSE AS | 1 | |
| 5895789 | 86 PLATE | 1 | |
| 5895790 | 87 PLATE | 1 | |
| 5896617 | 88 HOSE AS | 1 | |
| 5901387 | 89 HOSE AS | 1 | |
| 5M6213 | 90 PLUG-PIPE (1/4-18-THD) | 2 | |
| 5P3238 | 91 FITTING | 1 | |
| 5P4116 | 92 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 5P7464 | 93 CLIP (SLOT) | 10 | |
| 5P7465 | 94 CLIP (TAB) | 10 | |
| 5P7468 | 95 CLIP (SLOT) | 6 | |
| 5P7469 | 96 CLIP (TAB) | 6 | |
| 5P8444 | 97 GROMMET (37-MM ID) | 3 | |
| 6B9081 | 98 BUSHING-REDUCER | 1 | |
| 6D3479 | 99 CLIP (LOOP) | 1 | |
| 6K8178 | 100 CLIP (LOOP) | 1 | |
| 6L5955 | 101 ELBOW | 1 | |
| 6V0545 | 102 GROMMET | 3 | |
| 6V1249 | 103 GROMMET (22-MM ID) | 10 | |
| 6V8979 | 104 ELBOW | 1 | |
| 7G5984 | 105 CLIP (TAB) | 2 | |
| 7G5985 | 106 CLIP (SLOT) | 2 | |
| 7X0492 | 107 ELBOW | 2 | |
| 7X0613 | 108 WASHER-HARD (8.8X25.5X5-MM THK) | 3 | |
| 7X2535 | 109 BOLT (M6X1X60-MM) | 4 | |
| 7X2539 | 110 BOLT (M8X1.25X110-MM) | 3 | |
| 7X5331 | 111 ELBOW | 1 | |
| 7X7729 | 112 WASHER (11X25X3-MM THK) | 3 | |
| 8B2664 | 113 BUSHING-REDUCER | 1 | |
| 8C6444 | 114 TEE-BULKHEAD | 1 | |
| 8C6865 | 115 CONNECTOR | 2 | |
| 8C6866 | 116 CONNECTOR | 3 | |
| 8J4788 | 117 FITTING-ELBOW | 1 | |
| 8T4121 | 118 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4137 | 119 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4182 | 120 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4186 | 121 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4194 | 122 BOLT (M12X1.75X50-MM) | 3 | |
| 8T4196 | 123 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4205 | 124 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4223 | 125 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T5005 | 126 BOLT (M10X1.5X70-MM) | 1 | |
| 8T9043 | 127 BOLT (5/16-18X0.875-IN) | 3 | |
| 8T9364 | 128 BOLT (1/4-20X0.625-IN) | 2 | |
| 8X6293 | 129 ELBOW | 1 | |
| 9M8406 | 130 CLIP (LOOP) | 5 | |
| 9X8250 | 131 CLIP (LOOP) | 2 | |
| 9X8256 | 132 WASHER (6.6X12X2-MM THK) | 6 | |
| 5400200 | KIT-O-RING | 1 |
