System And Components
280-2056 WHEEL & BRAKE GPS/N 4AR1-UP
Group No: 280-2056
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3801397 | 1 SEAL-O-RING | 1 | |
| 5B3265 | 2 GASKET | 2 | |
| 6B5262 | 3 PLUG (FRONT WHEEL OIL DRAIN) | 1 | |
| 7I5617 | 4 SHIM PACK (INCLUDES 19-SHIMS) | 1 | |
| 8M3837 | 5 PLUG-MAGNETIC (FRONT WHEEL, OIL FILL) | 1 | |
| 8X2607 | 6 SHIM PACK (INCLUDES 20-SHIMS) | 2 | |
| 8X2608 | 7 PLATE | 1 | |
| 9W7095 | 8 CONE-BEARING (TAPERED ROLLER) | 1 | |
| 9W7096 | 9 CUP-BEARING | 1 | |
| 1237270 | 10 SEAL-RING | 1 | |
| 1255938 | 11 WHEEL-FRONT | 1 | |
| 1425636 | 12 RETAINER | 1 | |
| 1747531 | 13 SPINDLE AS | 1 | |
| 3755961 | 14 RETAINER | 1 | |
| 2903829 | 15 CONE-SPECIAL TAPERED | 1 | |
| 2903830 | 16 CUP-SPECIAL TAPERED | 1 | |
| 2920162 | 17 COVER | 1 | |
| 2994737 | 18 COVER | 1 | |
| 2994746 | 19 PLATE | 2 | |
| 3088498 | 20 PLATE | 1 | |
| 3144126 | 21 SEAL GP-DUO-CONE | 1 | |
| 3144125 | 21A RING-TORIC | 2 | |
| 3144130 | 22 SEAL GP-DUO-CONE | 1 | |
| 3144129 | 22A RING-TORIC | 2 | |
| 3345020 | 23 BRAKE GP-SERVICE & PARKING (FRONT) | 1 | |
| 3462140 | 24 PLATE GP-AXLE IDENTIFICATION | 1 | |
| 1052793 | PLATE-SERIAL NUMBER (FRONT WHEEL) | 1 | |
| 3298934 | TAPE | ||
| 1459278 | 25 BOLT (M20X2.5X90-MM) | 14 | |
| 2B0858 | 26 PLUG-PIPE | 1 | |
| 4S5879 | 27 SEAL-O-RING | 1 | |
| 6V3689 | 28 SEAL-O-RING | 1 | |
| 6V3967 | 29 SEAL-O-RING | 1 | |
| 7X7729 | 30 WASHER (11X25X3-MM THK) | 6 | |
| 8C3236 | 31 BOLT (M30X3.5X160-MM) | 12 | |
| 8M4436 | 32 SEAL-O-RING | 1 | |
| 8T3282 | 33 WASHER-HARD (22X35X3.5-MM THK) | 14 | |
| 8T4194 | 34 BOLT (M12X1.75X50-MM) | 12 | |
| 8T4196 | 35 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 9X2199 | 37 BOLT (M30X3.5X50-MM) | 10 | |
| 9X7310 | 38 RING-SEAL | 1 | |
| 9X8399 | 39 WASHER (33X56X6-MM THK) | 12 |
