System And Components
111-8830 BLADE GP-LEVELINGS/N 4JZ1-UP; 5BZ1-UP
Group No: 111-8830
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1094416 | 1 BLADE AS | 1 | |
| 8G4189 | 2 BEARING-SELF-ALIGNING | 2 | |
| 1110279 | 3 SPACER | 4 | |
| 9X6496 | 4 RING-RETAINING | 4 | |
| 1110280 | 5 BUSHING | 2 | |
| 7X2584 | 6 BOLT (M30X3.5X140-MM) | 2 | |
| 7X5677 | 7 WASHER | 4 | |
| 8C8722 | 8 NUT (M30X3.5-THD) | 2 | |
| 1110276 | 9 PLATE | 2 | |
| 1110278 | 10 BAR | 2 | |
| 1110277 | 11 PLATE | 2 | |
| 1110574 | 12 SHIM | 4 | |
| 8T4170 | 13 BOLT (M20X2.5X150-MM) | 3 | |
| 8T4123 | 14 WASHER (22X35X3.5-MM THK) | 12 | |
| 6V7688 | 15 LOCKNUT (M20X2.5-THD) | 6 | |
| 1382274 | 16 CYLINDER GP-HYDRAULIC | 1 | |
| 7X0436 | 17 BOLT (1-1/4-7X9-IN) | 1 | |
| 7X0533 | 18 WASHER-HARD (34X55X6-MM THK) | 4 | |
| 2J5997 | 19 LOCKNUT (1-1/4-7-THD) | 2 | |
| 7X0429 | 20 BOLT (1-1/4-7X4.5-IN) | 1 | |
| 0775470 | 21 BUSHING-TERMINAL | 1 | |
| 1026745 | 22 EDGE-CUTTING (MID-SECTION) | 1 | |
| 1094426 | 23 EDGE-CUTTING | 2 | |
| 4F3654 | 24 BOLT-PLOW (5/8-11X2-IN) | 18 | |
| 8T4122 | 25 WASHER-HARD (17X32X3.5-MM THK) | 18 | |
| 3E9861 | 26 LOCKNUT (5/8-11-THD) | 18 | |
| 7X5689 | 27 PLATE-WEAR | 2 | |
| 3B8489 | 28 FITTING-GREASE | 3 | |
| 9F2247 | 29 PLUG-PIPE (1/8-27-THD) | 1 | |
| 8C8478 | 30 BOLT (M20X2.5X140-MM) | 3 |
