System And Components
579-1782 COVER GP-ENGINES/N AX71-UP
Group No: 579-1782
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4566 | 1 BOLT (1/2-13X3.5-IN) | 8 | |
| 0341432 | 3 STRAP-CABLE | 15 | |
| 0S0509 | 4 BOLT (3/8-16X0.75-IN) | 2 | |
| 1102570 | 5 CAP | 2 | |
| 1138194 | 6 CAP | 2 | |
| 1291609 | 8 SEAL-O-RING | 1 | |
| 1W4161 | 10 CLAMP | 2 | |
| 2086055 | 11 CLAMP | 1 | |
| 2094573 | 12 CLAMP-T BOLT | 2 | |
| 2094581 | 13 CLAMP-T BOLT | 6 | |
| 2287092 | 14 SEAL-O-RING | 2 | |
| 2313264 | 15 CLAMP (BOLT SPRING) | 8 | |
| 2338484 | 16 CLAMP (BOLT SPRING) | 4 | |
| 2954202 | 18 COVER | 1 | |
| 2987137 | 19 BOLT (M16X2X50-MM) | 4 | |
| 2N5006 | 20 BOLT-12 POINT HEAD (1-14X2.5-IN) | 6 | |
| 2Y5741 | 21 COVER | 2 | |
| 3072670 | 22 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3E7442 | 23 BOLT (M30X3.5X300-MM) | 2 | |
| 4J5477 | 24 SEAL-O-RING | 1 | |
| 4P5085 | 25 COVER | 2 | |
| 4W3754 | 26 BOOT | 2 | |
| 5793327 | 27 STAND | 1 | |
| 5796092 | 28 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 5N4432 | 29 BOOT | 5 | |
| 5N4447 | 30 BOOT | 1 | |
| 5N4454 | 31 BOOT | 2 | |
| 5P0597 | 32 CLAMP-HOSE | 3 | |
| 5P0599 | 33 CLAMP-BAND | 1 | |
| 5P1076 | 34 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P2909 | 35 PLUG | 5 | |
| 5P3860 | 36 CLAMP-HOSE | 4 | |
| 5P3945 | 37 CAP | 1 | |
| 5P3946 | 38 PLUG | 1 | |
| 5P3950 | 39 CAP | 1 | |
| 5P3951 | 40 PLUG | 1 | |
| 5P4868 | 41 CLAMP-HOSE | 3 | |
| 5P8086 | 42 BOLT-12 POINT HEAD (1-14X6.5-IN) | 6 | |
| 6V8397 | 43 SEAL-O-RING | 1 | |
| 6V9507 | 44 PLUG | 1 | |
| 6V9508 | 45 PLUG (11/16-16-THD) | 1 | |
| 6V9510 | 46 PLUG (1-14-THD) | 1 | |
| 6V9511 | 47 PLUG (1-3/16-12-THD) | 1 | |
| 6V9828 | 48 CAP (ORFS) | 1 | |
| 6V9829 | 49 CAP (ORFS) | 1 | |
| 6V9831 | 50 CAP (ORFS) | 2 | |
| 6V9832 | 51 CAP (ORFS) | 1 | |
| 6W7379 | 52 PLUG | 1 | |
| 7E4227 | 53 CAP | 1 | |
| 7H2903 | 54 PLUG-PROTECTION | 3 | |
| 7J9108 | 55 SEAL-O-RING | 2 | |
| 7N4083 | 56 BOOT | 4 | |
| 7N7820 | 57 BOOT | 1 | |
| 7X2563 | 58 BOLT (M20X2.5X60-MM) | 8 | |
| 8C8722 | 59 NUT (M30X3.5-THD) | 2 | |
| 8N1663 | 60 BOOT | 3 | |
| 8N9033 | 61 PLUG | 3 | |
| 8S4951 | 62 CAP (FLARED) | 5 | |
| 8T1757 | 63 NUT (M16X2-THD) | 8 | |
| 8T4121 | 64 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4132 | 65 NUT (M16X2-THD) | 4 | |
| 8T4186 | 66 BOLT (M10X1.5X40-MM) | 8 | |
| 8T4194 | 67 BOLT (M12X1.75X50-MM) | 4 | |
| 8T6703 | 68 CLAMP-HOSE | 2 | |
| 8T6726 | 69 CLAMP-HOSE | 5 | |
| 8T7013 | 70 BOLT (M16X2X220-MM) | 8 | |
| 9N6379 | 71 BOOT | 2 | |
| 9S8895 | 72 PLUG | 2 | |
| 9S8896 | 73 CAP (FLARED 37-DEG) | 2 | |
| 9U7071 | 74 CAP/PLUG-TAPERED | 2 | |
| 9U7085 | 75 CAP/PLUG-TAPERED | 2 | |
| 1654935 | 76 PLUG AS | 1 | |
| 6V9510 | PLUG (1-14-THD) | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1256729 | 77 COVER | 2 | |
| 6V9830 | 78 CAP (ORFS) | 2 | |
| 6V9509 | 79 PLUG (13/16-16-THD) | 2 | |
| 6V8398 | 80 SEAL-O-RING | 2 | |
| 3E4096 | 81 CAP | 23 | |
| 5T6321 | 82 PLATE | 8 | |
| 5P2228 | 83 BOLT (1/2-13X1-IN) | 8 | |
| 4B4280 | 84 WASHER (13.5X27X2.5-MM THK) | 8 | |
| 2144670 | 85 GASKET | 2 |
