System And Components
144-0742 AIR COMPRESSOR GPPART OF 8N-8360 AIR COMPRESSOR GP
Group No: 144-0742
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B4505 | 1 LOCKWASHER | 4 | |
| 2B2695 | 2 BOLT (5/16-18X0.875-IN) | 4 | |
| 8M7065 | 3 GASKET (AIR INLET) | 1 | |
| 9M0397 | 4 ADAPTER | 1 | |
| 4W9479 | 5 MANIFOLD-EXHAUST | 1 | |
| 1S7107 | 6 GASKET | 1 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 7X7732 | 8 PLUG-PIPE | 2 | |
| 1A2029 | 9 BOLT (3/8-16X1.125-IN) | 6 | |
| 3B4506 | 10 LOCKWASHER | 6 | |
| 7N7442 | 11 GASKET | 2 | |
| 0344160 | 12 BOLT-LOCKING (5/16-18X1-IN) | 8 | |
| 8T6762 | 13 PLUG-PIPE (1/2-14-THD) | 1 | |
| 7N7446 | 14 GASKET | 1 | |
| 8H9789 | 15 BALL BEARING | 2 | |
| 7N7445 | 16 CYLINDER BLOCK | 1 | |
| 7N7448 | 17 GASKET | 1 | |
| 7N7447 | 18 HEAD AS-COMPRESSOR | 1 | |
| 5L5502 | FITTING | 1 | |
| 1245572 | VALVE AS-RELIEF (AIR COMPRESSOR) | 1 | |
| 0S1619 | 19 BOLT (3/8-16X3-IN) | 5 | |
| 7N7450 | 20 COVER-UNLOADER | 1 | |
| 3B4504 | 21 LOCKWASHER | 2 | |
| 0S1615 | 22 BOLT (1/4-20X0.75-IN) | 2 | |
| 7N7451 | 23 GASKET-UNLOADER | 1 | |
| 0L1352 | 24 BOLT (3/8-16X3.25-IN) | 1 | |
| 1W9276 | 25 CRANKSHAFT-AIR COMPRESSOR | 1 | |
| 1W9275 | 26 CRANKCASE-COMPRESSOR | 1 | |
| 1W9277 | 27 COVER-AIR COMPRESSOR | 1 | |
| 1W9279 | 28 SEAL | 1 | |
| 1W9278 | 29 COVER-AIR COMPRESSOR | 1 | |
| 6F7063 | 30 NUT-SLOTTED | 1 | |
| 5P8026 | 31 PIN-COTTER | 1 | |
| 4H3157 | 32 KEY-WOODRUFF | 1 | |
| 4W9489 | 33 RING-LOCK | 1 | |
| 7N7435 | KIT-AIR COMPRESSOR (MAJOR REPAIR) | 1 | |
| 4P6409 | KIT-PIN (AIR COMPRESSOR) | 1 | |
| 1440503 | KIT-PISTON & RING (STANDARD)(AIR COMPRESSOR) | 1 | |
| 1440502 | KIT-PISTON RING (STANDARD)(AIR COMPRESSOR) | 1 | |
| 1382887 | KIT-ROD & BEARING (AIR COMPRESSOR) | 1 |
