System And Components
486-8367 MOUNTING GP-ENGINE & XMSNS/N PDY1-UP
Group No: 486-8367
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6Y9980 | 1 MOUNT AS | 2 | |
| 9W8095 | PAD-REBOUND | 1 | |
| 9W9958 | MOUNT | 1 | |
| 1905271 | 2 BRACKET (LH) | 1 | |
| 1905272 | 3 BRACKET (RH) | 1 | |
| 4868434 | 4 SUPPORT AS | 2 | |
| 2765477 | 5 WASHER-HARD (34.9X7602X6-MM THK) | 2 | |
| 3E4887 | 6 SLEEVE | 2 | |
| 3E4888 | 7 WASHER (32X144X12-MM THK) | 2 | |
| 7X2555 | 8 BOLT (M16X2X80-MM) | 12 | |
| 7X2586 | 9 BOLT (M30X3.5X180-MM) | 2 | |
| 8C8722 | 10 NUT (M30X3.5-THD) | 2 | |
| 9X8257 | 11 WASHER (17.5X30X3.5-MM THK) | 12 | |
| 9X8258 | 12 WASHER (33X56X6-MM THK) | 2 |
