System And Components
549-6925 WIRING GP-GENERATOR -VOLTAGE REGULATORS/N GF51-UP
Group No: 549-6925
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 11 | |
| 5P8500 | 2 KEY (CORPORATE) | 1 | |
| 7K1181 | 3 STRAP-CABLE | 4 | |
| 2750572 | 4 LATCH AS | 2 | |
| 2933081 | 5 CAM-LATCH | 3 | |
| 3149093 | 6 BAR-FIXED BRIDGE | 1 | |
| 3716434 | 7 LATCH AS | 1 | |
| 0996418 | 8 NUT (M6X1-THD) | 5 | |
| 1566175 | 9 CLIP (LADDER) | 1 | |
| 1984775 | 10 WASHER-HARD (6.6X15X6-MM THK) | 30 | |
| 2939452 | 11 MOUNTING-CABLE TIE | 20 | |
| 3434072 | 12 BOLT-FLANGE HEAD (M6X1X25-MM) | 4 | |
| 3445673 | 13 NUT (M6X1-THD) | 10 | |
| 4914001 | 14 STRIP GP-TERMINAL | 1 | |
| 4915854 | 15 COVER AS | 1 | |
| 5496926 | 16 HARNESS AS-PANEL | 1 | |
| 1127497 | END-WIRE (14-GA) | 1 | |
| 2L8077 | TERMINAL-RING (14-GA TO 16-GA, 1/4-IN SCREW) | 1 | |
| 8C8451 | 17 BOLT (M6X1X40-MM) | 10 | |
| 8T4171 | 18 BOLT (M6X1X12-MM) | 7 | |
| 8T4971 | 19 BOLT (M6X1X30-MM) | 10 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 7 | |
| 2177165 | 21 DUCT-WIRE (600-MM) | ||
| 8T9005 | 22 SEAL (248-CM) |
