System And Components
491-4000 WIRING GP-GENERATOR -VOLTAGE REGULATORS/N TZK1-UP; FLX1-UP
Group No: 491-4000
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 11 | |
| 5P8500 | 2 KEY | 1 | |
| 7K1181 | 3 STRAP-CABLE | 5 | |
| 2750572 | 4 LATCH AS | 2 | |
| 2933081 | 5 CAM-LATCH | 3 | |
| 3716434 | 6 LATCH AS | 1 | |
| 4914004 | 7 HARNESS AS-PANEL (VOLTAGE REGULATOR) | 1 | |
| 0996418 | 8 NUT (M6X1-THD) | 5 | |
| 1566175 | 9 CLIP (LADDER) | 1 | |
| 1984775 | 10 WASHER-HARD (6.6X15X6-MM THK) | 30 | |
| 2939452 | 11 MOUNTING-CABLE TIE | 20 | |
| 3434072 | 12 BOLT-FLANGE HEAD (M6X1X25-MM) | 4 | |
| 3445673 | 13 NUT (M6X1-THD) | 10 | |
| 4914001 | 14 STRIP GP-TERMINAL (VOLTAGE REGULATOR) | 1 | |
| 4915854 | 15 COVER AS | 1 | |
| 8C8451 | 16 BOLT (M6X1X40-MM) | 10 | |
| 8T4171 | 17 BOLT (M6X1X12-MM) (M6X1X12-MM) | 7 | |
| 8T4971 | 18 BOLT (M6X1X30-MM) | 10 | |
| 9X8256 | 19 WASHER (6.6X12X2-MM THK) | 7 | |
| 2177165 | 20 DUCT-WIRE (600-MM) | ||
| 8T9005 | 21 SEAL (248-CM) |
