System And Components
380-1057 LINES GP-FUELPROVIDES A FUEL COOLED LINES GROUP FOR LEFT HAND COMMERICAL ENGINE
Group No: 380-1057
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0707 | 1 CLAMP AS | 4 | |
| 3078373 | GROMMET | 1 | |
| 9N5550 | 2 BRACKET | 1 | |
| 3328542 | 3 TEE AS | 1 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 3750296 | 4 HOSE AS | 1 | |
| 3824527 | 5 HOSE AS | 1 | |
| 3824925 | 6 HOSE AS | 1 | |
| 3833327 | 7 BRACKET AS | 1 | |
| 2287090 | 8 SEAL-O-RING | 1 | |
| 3196225 | 9 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196226 | 10 ELBOW AS | 2 | |
| 8T6876 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196233 | 11 TEE AS | 1 | |
| 6V8782 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3537957 | 12 GROMMET | 1 | |
| 4L6459 | 13 BOLT (3/8-16X2.5-IN) | 1 | |
| 5P1075 | 14 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 5P2424 | 15 BOLT (1/2-13X2.25-IN) | 1 | |
| 5S7383 | 16 BOLT (3/8-16X1.75-IN) | 1 | |
| 5V9221 | 17 SPACER (13.8X25X25-MM THK) | 1 | |
| 6V8801 | 18 NUT (3/8-16-THD) | 2 | |
| 6V9830 | 19 CAP (ORFS) | 1 | |
| 8C8989 | 20 ELBOW | 1 | |
| 8T1887 | 21 CLIP (SLOT) | 1 | |
| 8T1888 | 22 CLIP (TAB) | 1 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T9377 | 24 BOLT (3/8-16X2.25-IN) | 1 |
