448-1305 LINES GP-TURBOCHARGER OILS/N K1H1-UP

Group No: 448-1305
Part NumberPart NameQty
24940131 COVER2
31711262 HOSE AS2
44813073 HOSE AS1
45200514 HOSE AS1
22870905 SEAL-O-RING4
22871036 SEAL-O-RING1
26815537 ELBOW AS1
2287090SEAL-O-RING1
2287103SEAL-O-RING1
2681552ELBOW1
2Y58298 NUT (M10X1.5-THD)2
30177919 CLIP (SLOT)2
301779210 CLIP (TAB)2
353795411 GROMMET2
6V182012 BOLT (M10X1.5X30-MM)2
6V526613 SEAL-O-RING2
6V583914 WASHER (11X21X2.5-MM THK)4
6V631715 BOLT (M10X1.5X20-MM)4
332854216 TEE AS2
6V9844TEE-SWIVEL1
2287090SEAL-O-RING2
8C898917 ELBOW3
8T749018 CONNECTOR-TUBE1
3E435319 WASHER-HARD (11X25X3-MM THK)4
