System And Components
434-7415 LINES GP-FUELS/N BDN1-UP
Group No: 434-7415
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0341432 | 1 STRAP-CABLE | 4 | |
| 3307736 | 2 HOSE AS | 1 | |
| 3447826 | 3 MANIFOLD-FUEL | 1 | |
| 3447865 | 4 TUBE AS-FUEL SUPPLY | 1 | |
| 3528928 | 5 REGULATOR GP-FUEL PRESSURE | 1 | |
| 3535133 | 6 ELBOW AS | 1 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3535134 | 7 ELBOW AS | 1 | |
| 1184728 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3540192 | 8 BRACKET AS | 1 | |
| 3543517 | 9 LINE-FUEL | 1 | |
| 3543518 | 10 LINE-FUEL | 1 | |
| 3560419 | 11 LINE-FUEL | 1 | |
| 3563485 | 12 BRACKET AS | 1 | |
| 3679094 | 13 LINE AS-FUEL | 1 | |
| 3893708 | 14 PLUG AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 4201795 | 15 VALVE GP-CHECK (FUEL) | 1 | |
| 0919035 | 16 SPACER (11X25X20-MM THK) | 1 | |
| 0S1591 | 17 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1618 | 18 BOLT (5/16-18X1-IN) | 2 | |
| 1275447 | 19 SPACER (10.5X20X12-MM THK) | 1 | |
| 1640150 | 20 SPACER (9X20X20-MM THK) | 1 | |
| 1A2029 | 21 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A4273 | 22 BOLT (5/8-18X1.25-IN) | 1 | |
| 1B2713 | 23 BOLT (1/4-20X1.75-IN) | 2 | |
| 1C2251 | 24 BOLT (3/8-16X1.87-IN) | 2 | |
| 2P1281 | 25 ADAPTER-STRAINER | 1 | |
| 3031506 | 26 ELBOW AS | 1 | |
| 4K6297 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3072673 | 27 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3095131 | 28 PLUG AS | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3139614 | 29 ADAPTER AS | 2 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3328555 | 30 ADAPTER AS | 1 | |
| 8M0506 | ADAPTER-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3353976 | 31 ELBOW AS | 1 | |
| 8T0119 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3491209 | 32 CLIP | 1 | |
| 3535108 | 33 ELBOW AS | 1 | |
| 2P7214 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3535111 | 34 ADAPTER AS | 1 | |
| 7D9984 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3537953 | 35 GROMMET | 2 | |
| 3537957 | 36 GROMMET | 2 | |
| 4W9149 | 37 SPACER (10.5X19X16.75-MM THK) | 1 | |
| 5M2894 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 5P0537 | 39 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P4116 | 40 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 5P8247 | 41 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 6V8189 | 42 NUT (5/16-18-THD) | 1 | |
| 7F2050 | 43 LOCKNUT (3/4-16-THD) | 1 | |
| 8T1887 | 44 CLIP (SLOT) | 2 | |
| 8T1888 | 45 CLIP (TAB) | 2 | |
| 8T1889 | 46 CLIP (SLOT) | 2 | |
| 8T1890 | 47 CLIP (TAB) | 2 | |
| 9M1974 | 48 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8752 | 49 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 50 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
