System And Components
364-7457 LINES GP-AIRS/N NAM1-UP
Group No: 364-7457
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S4305 | 1 SPACER (0.531X1X0.56-IN THK) | 8 | |
| 7N6986 | 2 SUPPORT | 2 | |
| 1128989 | 3 SPACER (15.9X50.8X6.3-MM THK) | 16 | |
| 1356261 | 4 CLAMP | 16 | |
| 2478545 | 5 GASKET | 2 | |
| 2665360 | 6 WASHER (13X37X3-MM THK) | 4 | |
| 2726462 | 7 GASKET | 3 | |
| 2733538 | 8 HOSE | 4 | |
| 2826664 | 9 BELLOWS | 1 | |
| 2826678 | 10 BRACKET | 1 | |
| 2826679 | 11 CLAMP | 8 | |
| 2826680 | 12 STRAP | 4 | |
| 2828535 | 13 U-BOLT | 2 | |
| 2939809 | 14 CLIP-2 PIECE | 6 | |
| 2939810 | 15 CLIP-2 PIECE | 6 | |
| 3155339 | 16 SUPPORT GP-BRACE | 4 | |
| 3155342 | 17 CLAMP GP | 2 | |
| 3155340 | CLAMP | 1 | |
| 3155341 | CLAMP | 1 | |
| 3155345 | 18 CLAMP GP | 2 | |
| 3155343 | CLAMP | 1 | |
| 3155344 | CLAMP | 1 | |
| 2945249 | 19 BRACKET (LH) | 1 | |
| 2945250 | 20 BRACKET (RH) | 1 | |
| 2952847 | 21 BRACKET (LH) | 1 | |
| 2952848 | 22 BRACKET (RH) | 1 | |
| 3184305 | 23 SPACER | 2 | |
| 3186036 | 24 TUBE | 1 | |
| 3186037 | 25 TUBE | 1 | |
| 3249862 | 26 PLATE | 1 | |
| 3249863 | 27 BRACKET AS | 1 | |
| 3310223 | 28 BRACKET AS | 2 | |
| 3310224 | 29 BRACKET AS | 2 | |
| 1J2560 | 39 PIPE | 2 | |
| 3P0648 | 40 SEAL-O-RING | 16 | |
| 4L6454 | 41 BOLT (3/8-16X1-IN) | 8 | |
| 5P1075 | 42 WASHER-HARD (10.2X22.5X3-MM THK) | 30 | |
| 5P1076 | 43 WASHER-HARD (13.5X30X4-MM THK) | 12 | |
| 5P2566 | 44 BOLT (1/2-13X1.5-IN) | 12 | |
| 5S7383 | 45 BOLT (3/8-16X1.75-IN) | 8 | |
| 6V8182 | 46 NUT (3/4-10-THD) | 16 | |
| 6V8188 | 47 NUT (1/2-13-THD) | 20 | |
| 6V8801 | 48 NUT (3/8-16-THD) | 32 | |
| 7X0311 | 49 BOLT (7/16-14X2.25-IN) | 4 | |
| 7X0369 | 50 BOLT (3/4-10X3.25-IN) | 16 | |
| 7X0373 | 51 BOLT (3/4-10X5.5-IN) | 8 | |
| 7X0375 | 52 BOLT (3/4-10X5-IN) | 8 | |
| 7X0447 | 53 NUT (7/16-14-THD) | 4 | |
| 7X0515 | 54 WASHER-HARD (17X35X5-MM THK) | 8 | |
| 7X0582 | 55 WASHER-HARD (20X44.5X6-MM THK) | 32 | |
| 7X2553 | 56 BOLT (M16X2X40-MM) | 8 | |
| 8C7323 | 57 BOLT (3/8-16X6-IN) | 2 | |
| 8C8842 | 58 BOLT (3/4-10X4-IN) | 8 | |
| 8T2501 | 59 BOLT (3/8-16X2-IN) | 12 | |
| 8T2502 | 60 BOLT (3/8-16X1.125-IN) | 6 | |
| 8T4223 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8T4896 | 62 WASHER-HARD (10.2X18.5X2.5-MM THK) | 44 | |
| 8T5360 | 63 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T8916 | 64 BOLT (7/16-14X1.5-IN) | 4 | |
| 8T8917 | 65 BOLT (1/2-13X1.25-IN) | 4 | |
| 8T9101 | 66 BOLT (3/8-16X2.75-IN) | 8 | |
| 8T9379 | 67 BOLT (3/8-16X4.25-IN) | 4 | |
| 9B7237 | 68 BOLT (3/8-16X1.25-IN) | 6 |
