System And Components
420-1854 WIRING GP-GENERATORS/N SFK1-UP
Group No: 420-1854
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6772 | 1 STRAP-CABLE | 29 | |
| 4201845 | 2 HARNESS AS-WIRING (AC) | 1 | |
| 4201852 | 3 HARNESS AS-POWER | 1 | |
| 4201853 | 4 HARNESS AS-WIRING (CURRENT TRANSFORMER) | 1 | |
| 1305300 | 5 CLIP | 2 | |
| 1984775 | 6 WASHER-HARD (6.6X15X6-MM THK) | 30 | |
| 1S6420 | 7 CLIP | 1 | |
| 2049734 | 8 SPACER (11X18X25-MM THK) | 3 | |
| 2939452 | 9 MOUNTING-CABLE TIE | 20 | |
| 3K8106 | 10 SCREW-MACHINE (8-32X1-IN) | 16 | |
| 4B2043 | 11 NUT (8-32-THD) | 16 | |
| 4B4863 | 12 WASHER (4.7X11X1.2-MM THK) | 32 | |
| 5C2890 | 13 NUT (M6X1-THD) | 10 | |
| 8C8451 | 14 BOLT (M6X1X40-MM) | 1 | |
| 8M2771 | 15 CLIP | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4182 | 18 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4244 | 20 NUT (M12X1.75-THD) | 5 | |
| 8T4971 | 21 BOLT (M6X1X30-MM) | 20 | |
| 9X8256 | 22 WASHER (6.6X12X2-MM THK) | 1 | |
| 8T4184 | 23 BOLT (M12X1.75X45-MM) | 4 |
