System And Components
510-6495 LINES GP-WATER -SEPARATE CIRCUIT AFTERCOOLERS/N GG31-UP
Group No: 510-6495
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 1 | |
| 2W5225 | 2 FLANGE | 2 | |
| 4W0530 | 3 RING-RETAINING | 4 | |
| 4W0531 | 4 RETAINER | 8 | |
| 9Y8069 | 5 GASKET | 1 | |
| 9S9635 | 6 JOINT AS-TUBE | 2 | |
| 9X7523 | SEAL | 2 | |
| 2044383 | 7 ELBOW | 1 | |
| 2046669 | 8 ADAPTER | 1 | |
| 2049736 | 9 HOSE AS | 1 | |
| 2086270 | 10 CLAMP | 2 | |
| 2106274 | 11 TUBE | 1 | |
| 2106275 | 12 TUBE | 1 | |
| 2106276 | 13 TUBE | 1 | |
| 2106277 | 14 TUBE | 1 | |
| 2140731 | 15 BRACKET | 1 | |
| 2154794 | 16 ELBOW | 2 | |
| 2154796 | 17 TUBE AS | 1 | |
| 2162285 | 18 JOINT AS-TUBE | 1 | |
| 1274230 | SEAL | 2 | |
| 2273805 | 19 HOUSING & REGULATOR GP | 1 | |
| 2304573 | 20 BRACKET | 3 | |
| 2309767 | 21 BRACKET | 1 | |
| 2490170 | 22 PLATE | 1 | |
| 5277377 | 23 PUMP GP-WATER | 1 | |
| 2733967 | 24 GASKET | 2 | |
| 3537953 | 25 GROMMET | 4 | |
| 3638651 | 26 BRACKET AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3650682 | 27 CONNECTOR | 2 | |
| 4186827 | 28 HOSE AS | 1 | |
| 4186828 | 29 HOSE AS | 1 | |
| 0L1351 | 30 BOLT (3/8-16X0.875-IN) | 4 | |
| 0L2070 | 31 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S0509 | 32 BOLT (3/8-16X0.75-IN) | 2 | |
| 1653931 | 33 BOLT (3/8-16X1.75-IN) | 7 | |
| 0S1585 | 34 BOLT (1/2-13X1.5-IN) | 6 | |
| 0S1587 | 35 BOLT (1/2-13X1.75-IN) | 8 | |
| 0S1588 | 36 BOLT (3/8-16X1.25-IN) | 6 | |
| 0S1594 | 37 BOLT (3/8-16X1-IN) | 17 | |
| 1A5822 | 38 BOLT (1/2-13X2.75-IN) | 2 | |
| 1F7958 | 39 NUT-FULL (1/2-13-THD) | 10 | |
| 2A2677 | 40 SPACER (10.7X17.14X19.05-MM THK) | 2 | |
| 3H8683 | 41 CLIP (SADDLE) | 4 | |
| 3J7354 | 42 SEAL-O-RING | 1 | |
| 3V3308 | 43 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 4J5477 | 44 SEAL-O-RING | 2 | |
| 4K0367 | 45 NUT-FULL (5/8-11-THD) | 4 | |
| 5H6734 | 46 SEAL-O-RING | 1 | |
| 5M2894 | 47 WASHER-HARD (10.2X18.5X2.5-MM THK) | 36 | |
| 5P8245 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 26 | |
| 6V1581 | 49 CLIP (SLOT) | 8 | |
| 6V1582 | 50 CLIP (TAB) | 8 | |
| 6V6809 | 51 SEAL-O-RING | 1 | |
| 6V8628 | 52 ELBOW | 1 | |
| 6V8733 | 53 UNION | 2 | |
| 6V9746 | 54 SEAL-O-RING | 6 | |
| 7X5331 | 55 ELBOW | 1 | |
| 8M9124 | 56 WASHER (10X22.5X8-MM THK) | 2 | |
| 8S6109 | 57 CLIP (SLOT) | 1 | |
| 8S6110 | 58 CLIP (TAB) | 1 | |
| 8T1919 | 59 SEAL-O-RING | 6 | |
| 8T6766 | 60 PLUG-PIPE | 5 | |
| 9C5344 | 61 SPACER (10.5X20X18-MM THK) | 1 | |
| 9L9132 | 62 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9S1366 | 63 BOLT (1/2-13X2.5-IN) | 1 | |
| 9S8752 | 64 NUT-FULL (3/8-16-THD) | 10 | |
| 2B0947 | 65 BOLT (1/2-13X2.25-IN) | 9 | |
| 8S9092 | 66 BOLT (5/8-11X2.25-IN) | 4 | |
| 9Y6893 | 67 GASKET | 2 | |
| 3717171 | 68 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3717226 | ADAPTER | 1 |
