System And Components
389-3073 MODULE GP-COOLINGS/N NDC1-UP; YEG1-UP; A9J1-UP
Group No: 389-3073 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2330060 | 1 FILM-IDENTIFICATION (LIFT EYE LOCATION) | 2 | |
| 3354189 | 2 CORE AS-AFTERCOOLER | 1 | |
| 3354190 | 3 CORE AS-OIL COOLER (HYDRAULIC) | 1 | |
| 3354191 | 4 CORE AS-RADIATOR | 1 | |
| 3355462 | 5 PIN | 16 | |
| 3364433 | 6 PIN | 8 | |
| 3387747 | 7 FRAME AS | 1 | |
| 3393869 | 8 SEAL-AIR | 1 | |
| 3393870 | 9 SEAL-AIR | 1 | |
| 3393871 | 10 SEAL-AIR | 4 | |
| 3629748 | 11 FRAME AS | 1 | |
| 3891576 | 12 FRAME AS | 1 | |
| 3893074 | 13 FRAME AS | 1 | |
| 1891943 | 14 LOCKNUT (M10X1.5-THD) | 12 | |
| 6E5293 | 15 BOLT (M10X1.5X210-MM) | 12 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 40 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 16 |
