385-1306 PUMP GP-FUEL TRANSFERS/N NDC1-UP

Group No: 385-1306 · Commonality
Part NumberPart NameQty
7K11811 STRAP-CABLE1
36852162 PUMP GP-FUEL TRANSFER1
36852193 CONNECTOR-HOSE1
50141864 VALVE GP-REFUELING (FOOT)1
44478415 FILM-INSTRUCTION (REFUELING PUMP)1
46105056 PLATE AS1
00657077 ELBOW-PIPE1
20422818 STRAP-CABLE2
20063459 SADDLE-MOUNTING (DUAL SWIVEL)1
2S164711 GROMMET1
8T412112 WASHER-HARD (11X21X2.5-MM THK)3
8T419513 BOLT (M10X1.5X30-MM)2
8T413714 BOLT (M10X1.5X20-MM)1
8T418315 BOLT (M12X1.75X40-MM)2
8T422316 WASHER-HARD (13.5X25.5X3-MM THK)2
9M795817 CLAMP-HOSE4
457115718 HOSE (453-CM)
457115718A HOSE (55-CM)
242609919 CLIP (LOOP)1
111483920 STRAP2
111483821 CLIP2
