System And Components
419-8528 FILTER GP-OIL -HYDRAULIC RETURNS/N NDC1-UP; YEG1-UP; A9J1-UP
Group No: 419-8528 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4198531 | 1 PLATE-SLIDE | 1 | |
| 1733529 | 2 BOLT (M6X1X15-MM) | 6 | |
| 3T7528 | 3 SEAL-O-RING | 6 | |
| 1733513 | 4 BASE | 1 | |
| 3E4297 | 5 SEAL-O-RING | 2 | |
| 1373626 | 6 BOLT-SPECIAL (M6X1X23.25-MM) | 1 | |
| 1799806 | 8 FILTER ELEMENT AS-OIL (ADVANCED EFFICIENCY)(HYDRAULIC RETURN) | 1 | |
| 1373623 | 9 SEAL-O-RING | 4 | |
| 6V7658 | 10 SEAL-O-RING | 2 | |
| 1772553 | 11 SEAL-O-RING | 1 | |
| 0951681 | 12 SEAL-O-RING | 1 | |
| 1733515 | 13 RING-RETAINING | 1 | |
| 1733516 | 14 HANDLE | 1 | |
| 4J7533 | 15 SEAL-O-RING | 1 | |
| 9S4180 | 16 PLUG | 1 | |
| 1373624 | 17 SCREW (M3X0.5X5-MM) | 8 | |
| 1373625 | 18 PAD | 2 | |
| 1733517 | 19 PLATE | 1 | |
| 1373628 | 20 SHIM (0.1-MM THK) | 1 | |
| 4198533 | 21 FILM-INSTRUCTION (HYDRAULIC OIL RETURN FILTER) | 1 | |
| 2019299 | KIT-SERVICE (HYDRAULIC RETURN FILTER) | 1 |
