System And Components
1W-4442 LINES GP-CENTRIFUGAL FILTER (CHG -08 THRU -13)CENTRIFUGAL RH
Group No: 1W-4442
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M4584 | 1 CONNECTOR | 4 | |
| 6V4589 | 2 SEAL-O-RING | 4 | |
| 3V3308 | 3 WASHER-HARD (10.2X20.5X2.5-MM THK) | 1 | |
| 0307951 | 4 ELBOW-FLARED | 2 | |
| 4W4061 | 5 TUBE AS | 2 | |
| 4W7533 | 6 TUBE AS | 1 | |
| 1240374 | 7 TUBE AS | 1 | |
| 3R6789 | 8 CAP-FLARED (1-5/16-12-THD) | 1 | |
| 0679921 | 9 TEE-FLARED | 1 | |
| 5P7701 | 10 SEAL-O-RING | 5 | |
| 7D7233 | 11 CLIP (LOOP) | 1 | |
| 1069573 | 12 TUBE AS | 1 | |
| 5P0912 | 13 ELBOW | 2 | |
| 0S1595 | 14 BOLT (1/2-13X1.25-IN) | 1 | |
| 6K5536 | 15 CLIP (TAB) | 2 | |
| 6K5535 | 16 CLIP (SLOT) | 2 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 0S1571 | 18 BOLT (3/8-16X1.75-IN) | 1 | |
| 6K5535 | 19 CLIP (SLOT) | 1 | |
| 6K5536 | 20 CLIP (TAB) | 1 | |
| 0L1352 | 21 BOLT (3/8-16X3.25-IN) | 1 | |
| 0919035 | 22 SPACER (11X25X20-MM THK) | 1 | |
| 7J0728 | 23 CLIP (TAB) | 1 | |
| 7J0729 | 24 CLIP (SLOT) | 1 | |
| 6E0549 | 25 ANGLE | 1 | |
| 1F7958 | 26 NUT-FULL (1/2-13-THD) | 1 | |
| 0S1621 | 27 BOLT (1/2-13X1-IN) | 1 | |
| 9S9334 | 28 PLUG (1-5/16-12-THD) | 1 | |
| 5P5598 | 29 SEAL-O-RING | 2 | |
| 1W4455 | 30 VALVE | 2 | |
| 0S1591 | 31 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1614 | 32 BOLT (1/4-20X0.5-IN) | 2 | |
| 5P0537 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1W4454 | 34 BODY-VALVE | 2 | |
| 0307935 | 35 CONNECTOR | 1 | |
| 1N3134 | 36 HOSE AS | 1 |
