4P-2372 LINES GP-CENTRIFUGAL FILTER (CHG -00 THRU -04, -04D1, -04D2, -04D3, -05, -05D1, -06, -06D1, -07-07D1 THRU -09)

Group No: 4P-2372
Part NumberPart NameQty
4P23431 TUBE AS1
4P23442 TUBE AS1
4P31173 VALVE-BALL (SHUTOFF)1
4S57184 CLIP1
6K55365 CLIP (TAB)2
09100816 SPACER (10.5X20X10-MM THK)2
4W91497 SPACER (10.5X19X16.75-MM THK)1
07296018 REDUCER (FLARED)2
14404039 TUBE AS1
147963410 HOSE AS1
009444011 CONNECTOR (FLARED)2
067992112 TEE-FLARED1
0L207013 BOLT (3/8-16X2.25-IN)1
0S159014 BOLT (3/8-16X2-IN)2
1P004315 NUT-FLARED (1-5/16-12-THD)2
3R678916 CAP-FLARED (1-5/16-12-THD)1
3V330817 WASHER-HARD (10.2X20.5X2.5-MM THK)1
5P224218 TEE-SWIVEL1
238508419 SEAL-O-RING1
6K553520 CLIP (SLOT)2
238508121 SEAL-O-RING2
9L913222 WASHER-HARD (10.2X25.5X2.5-MM THK)2
9M458423 CONNECTOR2
