Assembly
100%

119-3389 BYPASS GP-EXHAUST (CHG -00 THRU -04, -04D1, -04D2, -04D3)WASTEGATE

Group No: 119-3389
Part NumberPart NameQty
0S15851 BOLT (1/2-13X1.5-IN)36
2N27664 LOCKNUT (3/8-16-THD)52
2W04395 GASKET2
3B06456 PLUG-CUP (32.08-MM OD)2
5P60257 LOCKWIRE
5P71288 BOLT-HIGH TEMPERATURE (3/8-16X2-IN)8
5P82459 WASHER-HARD (13.5X25.5X3-MM THK)36
6I040710 THERMOCOUPLE2
6V152511 STUD-TAPERLOCK (3/8-16X2.16-IN)8
7C971012 GASKET2
7L644314 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN)36
7W911515 ADAPTER-EXHAUST2
7W919116 GASKET2
8M266517 BREATHER2
8T676618 PLUG-PIPE6
110831419 WASHER (10.3X18.3X2.66-MM THK)96
118241420 BYPASS GP-EXHAUST2
118249121 ELBOW2
118249222 HOUSING2
121396023 SHIELD AS2
218710524 BELLOWS AS2
133517925 GASKET6
149197626 THERMOWELL2
