System And Components
165-5013 BYPASS GP-EXHAUST (CHG -00, -00D1)FOR USE WITH FRONT MOUNTED TURBOCHARGER
Group No: 165-5013
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W6963 | 1 GASKET | 1 | |
| 2N2766 | 2 LOCKNUT (3/8-16-THD) | 102 | |
| 4J4382 | 3 PLUG-PIPE (1/2-14-THD) | 2 | |
| 4M9641 | 4 BOLT (1/2-13X12.75-IN) | 10 | |
| 4P0419 | 5 ADAPTER | 2 | |
| 5P2603 | 6 STUD-TAPERLOCK (3/8-16X1.57-IN) | 8 | |
| 6I0404 | 7 MANIFOLD-EXHAUST | 1 | |
| 6I0406 | 8 MANIFOLD-EXHAUST | 1 | |
| 6V8735 | 9 CAP | 2 | |
| 7C9710 | 10 GASKET | 2 | |
| 7W6340 | 11 GASKET | 1 | |
| 1108314 | 12 WASHER (10.3X18.3X2.66-MM THK) | 8 | |
| 1301300 | 13 SEAL | 1 | |
| 1345643 | 14 GASKET | 4 | |
| 1364185 | 15 BOLT (1/2-13X1.75-IN) | 8 | |
| 1367730 | 16 GASKET (CYLINDER HEAD) | 2 | |
| 1487273 | 17 SHIM | 10 | |
| 1537597 | 18 BYPASS GP-COMPRESSOR | 2 | |
| 1558158 | 19 COVER AS | 1 | |
| 1655014 | 20 HOUSING | 1 | |
| 1655015 | 21 BELLOWS AS | 6 | |
| 1657629 | 22 SUPPORT AS | 1 | |
| 1657630 | 23 ELBOW | 4 | |
| 1658983 | 24 GASKET | 18 | |
| 1660623 | 25 COVER | 2 | |
| 1662617 | 26 ADAPTER | 1 | |
| 1662618 | 27 ADAPTER | 1 | |
| 1663783 | 28 BRACE | 1 | |
| 0L1351 | 29 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S1588 | 30 BOLT (3/8-16X1.25-IN) | 30 | |
| 1403047 | 31 BOLT (3/8-16X1.125-IN) | 12 | |
| 3B1915 | 32 BOLT (3/8-16X1.375-IN) | 16 | |
| 3V3308 | 33 WASHER-HARD (10.2X20.5X2.5-MM THK) | 34 | |
| 5M2894 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P2755 | 35 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN) | 24 | |
| 5P8245 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 6V3250 | 37 SEAL-O-RING | 2 | |
| 7L6443 | 38 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN) | 68 | |
| 8C8491 | 39 WASHER-HARD (10.2X22X3-MM THK) | 196 | |
| 9S4191 | 40 PLUG (9/16-18-THD) | 2 |
