System And Components
116-2819 CARTRIDGE GP-TURBOCHARGER (CHG -00, -01)PART OF 4P-2366 TURBOCHARGER GP
Group No: 116-2819
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1006772 | 1 BOLT-HIGH TEMPERATURE (M8X1.25X16-MM) | 12 | |
| 7W0340 | 2 WHEEL AS-COMPRESSOR | 1 | |
| 4W8564 | 3 RING-SEAL | 1 | |
| 4W8573 | 4 PLATE-LOCK (0.8-MM THK) | 12 | |
| 4P0372 | 5 CONE-AIR | 1 | |
| 8T1159 | 6 BOLT-SOCKET HEAD (M10X1.5X25-MM) | 3 | |
| 3B4507 | 7 LOCKWASHER | 9 | |
| 4W7961 | 8 COVER AS | 1 | |
| 4W9032 | 9 SEAL-O-RING | 1 | |
| 4P0307 | 10 DISC-COVER | 1 | |
| 1162809 | 11 SHAFT AS-TURBINE | 1 | |
| 4W8564 | RING-SEAL | 1 | |
| 4W9030 | 12 BOLT (M18X1.5X31-MM) | 1 | |
| 4W8926 | WASHER (18.3X40X3.15-MM THK) | 1 | |
| 4W8572 | 13 PLATE-LOCK (1-MM THK) | 3 | |
| 4W9033 | 14 SEAL-O-RING | 1 | |
| 4W8683 | 15 COVER AS | 1 | |
| 4W9031 | 16 SEAL-O-RING | 1 | |
| 4W9293 | 17 BEARING AS (TURBINE) | 1 | |
| 4W8927 | 18 BUSHING-TERMINAL | 1 | |
| 8T0267 | 19 BOLT-SOCKET HEAD (M6X1X12-MM) | 3 | |
| 4W8561 | 20 BEARING AS-COMPRESSOR | 1 | |
| 4W8928 | 21 BUSHING-TERMINAL | 1 | |
| 8T0267 | 22 BOLT-SOCKET HEAD (M6X1X12-MM) | 4 | |
| 3B4504 | 22A LOCKWASHER | 4 | |
| 1300073 | 23 HOUSING-BEARING | 1 | |
| 8T1160 | 24 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 6 | |
| 7C3348 | 25 BEARING-THRUST | 1 | |
| 8C8581 | 26 BOLT-HIGH TEMPERATURE (M10X1.5X30-MM) | 3 |
