System And Components
126-4111 LINES GP-AIR (CHG -01 THRU -04, -04D1, -05)Type 2
Group No: 126-4111
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1571 | 1 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1615 | 2 BOLT (1/4-20X0.75-IN) | 2 | |
| 0S1587 | 3 BOLT (1/2-13X1.75-IN) | 2 | |
| 2D7325 | 4 TEE-PIPE | 1 | |
| 2N8142 | 5 TEE-SWIVEL | 1 | |
| 8T6767 | 6 PLUG-PIPE (3/8-18-THD) | 1 | |
| 3J7352 | 7 CONNECTOR | 1 | |
| 3J7355 | 8 UNION-FLARED | 1 | |
| 3P0764 | 9 PLUG | 1 | |
| 3S2093 | 10 STRAP-CABLE | 2 | |
| 3T3848 | 11 HOSE AS | 1 | |
| 3V3308 | 12 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 3V6153 | 13 HOSE AS | 2 | |
| 4D6988 | 14 CLIP | 2 | |
| 4F7957 | 15 BOLT (1/4-20X0.875-IN) | 4 | |
| 4S6399 | 16 CONNECTOR | 8 | |
| 2V5956 | 17 HOSE AS | 1 | |
| 5K3294 | 18 CLIP | 1 | |
| 5M6213 | 19 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P0537 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5T4374 | 22 HOSE AS | 1 | |
| 5T4375 | 23 HOSE AS | 1 | |
| 6K1972 | 24 ELBOW-FLARED | 1 | |
| 6N8659 | 25 HOSE AS | 1 | |
| 6V4589 | 26 SEAL-O-RING | 1 | |
| 6V5048 | 27 SEAL-O-RING | 2 | |
| 7C0370 | 28 TUBE AS | 1 | |
| 7C0371 | 29 TUBE AS | 1 | |
| 7C0372 | 30 BRACKET | 2 | |
| 7C0822 | 31 TUBE AS | 1 | |
| 7E0872 | 32 BRACKET AS | 1 | |
| 7K6462 | 33 ELBOW | 2 | |
| 7K9197 | 34 ELBOW | 5 | |
| 8L6005 | 35 TEE-PIPE | 1 | |
| 8N8471 | 36 CLAMP-TUBE | 2 | |
| 9G4523 | 37 HOSE AS | 1 | |
| 9S8750 | 38 NUT-FULL (1/4-20-THD) | 4 | |
| 9X7206 | 39 VALVE-SOLENOID (24-VOLT) | 1 | |
| 9X8873 | 40 BOLT (1/2-13X2.25-IN) | 2 | |
| 0016449 | 41 CONNECTOR | 2 | |
| 0032143 | 42 ELBOW | 1 | |
| 0307946 | 43 ELBOW | 1 | |
| 0307961 | 44 ELBOW | 1 | |
| 0676495 | 45 ELBOW-FLARED | 1 | |
| 4485598 | 46 SWITCH AS-PRESSURE (AIR) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X1813 | SLEEVE (15-CM) | ||
| 1667656 | 47 CONNECTOR-SOCKET (AIR PRESSURE) | 1 | |
| 1667657 | 48 CONNECTOR-PLUG | 1 | |
| 1667658 | 49 GASKET | 1 |
