System And Components
146-8982 LINES GP-AIR -AFTERCOOLER (CHG -03, -04, -04D1, -04D2, -04D3-04D4 THRU -08, -08D1, -08D2, -09)SHUTOFF, 24-VOLT
Group No: 146-8982
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3J7355 | 1 UNION-FLARED | 2 | |
| 5B3254 | 2 NUT-JAM (7/16-20-THD) | 1 | |
| 6N8659 | 3 HOSE AS | 1 | |
| 9R6247 | 4 STRAP-CABLE | 3 | |
| 9X7206 | 5 VALVE-SOLENOID (24-VOLT)(AIR SHUTOFF) | 1 | |
| 0904885 | 6 TIE-PUSH MOUNT | 2 | |
| 1220290 | 7 HOSE AS | 1 | |
| 1597926 | 8 PLATE | 1 | |
| 1598360 | 9 TUBE AS | 1 | |
| 1598362 | 10 TUBE AS | 1 | |
| 1667656 | 11 CONNECTOR-SOCKET | 1 | |
| 1667657 | 12 CONNECTOR-PLUG | 1 | |
| 1667658 | 13 GASKET | 1 | |
| 1934652 | 14 SHUTOFF GP-AIR | 1 | |
| 2274056 | 15 GASKET | 2 | |
| 2638971 | 16 TUBE AS | 1 | |
| 0S0509 | 17 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1591 | 18 BOLT (3/8-16X1.5-IN) | 10 | |
| 0S1621 | 19 BOLT (1/2-13X1-IN) | 3 | |
| 2P7216 | 20 ELBOW | 1 | |
| 3E7402 | 21 CONNECTOR | 2 | |
| 3L2875 | 22 CLIP | 4 | |
| 3V3308 | 23 WASHER-HARD (10.2X20.5X2.5-MM THK) | 11 | |
| 4F7957 | 24 BOLT (1/4-20X0.875-IN) | 4 | |
| 5P0537 | 25 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5P4479 | 26 ELBOW (FLARED-LONG) | 1 | |
| 5P8245 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 6K6967 | 28 ADAPTER-PIPE | 1 | |
| 7K9197 | 29 ELBOW | 3 | |
| 8L6557 | 30 CONNECTOR | 1 | |
| 8T6764 | 31 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9C7868 | 32 PLATE | 1 | |
| 9S8750 | 33 NUT-FULL (1/4-20-THD) | 4 | |
| 6V4245 | 34 ELBOW | 1 | |
| 6K6967 | 35 ADAPTER-PIPE | 1 |
