System And Components
147-7705 LINES GP-AIR (CHG -00, -00D1)SHUTOFF-24V DC
Group No: 147-7705
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W4766 | 1 GASKET | 1 | |
| 3F2065 | 2 LOCKNUT (1/2-14-THD) | 1 | |
| 3J7355 | 3 UNION-FLARED | 1 | |
| 5B3254 | 4 NUT-JAM (7/16-20-THD) | 1 | |
| 5N8943 | 5 ADAPTER | 1 | |
| 5N9073 | 6 CLIP | 1 | |
| 5T4375 | 7 HOSE AS | 1 | |
| 6K6967 | 8 ADAPTER-PIPE | 1 | |
| 6V4245 | 9 ELBOW | 1 | |
| 7C8265 | 10 VALVE-SOLENOID | 1 | |
| 7C9555 | 11 TUBE AS | 1 | |
| 7W6340 | 12 GASKET | 2 | |
| 7W7629 | 13 HOUSING | 1 | |
| 9C7868 | 14 PLATE | 1 | |
| 9R6247 | 15 STRAP-CABLE | 3 | |
| 9S4191 | 16 PLUG (9/16-18-THD) | 3 | |
| 0904885 | 17 TIE-PUSH MOUNT | 2 | |
| 1191858 | 18 SHUTOFF GP-AIR | 1 | |
| 1477645 | 19 ELBOW | 1 | |
| 1477702 | 20 HOUSING | 1 | |
| 1477703 | 21 ELBOW | 1 | |
| 1477704 | 22 BELLOWS AS | 2 | |
| 1597926 | 23 PLATE | 1 | |
| 1598360 | 24 TUBE AS | 1 | |
| 1598362 | 25 TUBE AS | 1 | |
| 0S0509 | 26 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1587 | 27 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 28 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1591 | 29 BOLT (3/8-16X1.5-IN) | 32 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 24 | |
| 0S1621 | 31 BOLT (1/2-13X1-IN) | 3 | |
| 1A1460 | 32 BOLT (1/2-13X2-IN) | 10 | |
| 1F7958 | 33 NUT-FULL (1/2-13-THD) | 10 | |
| 2P1314 | 34 CONNECTOR | 1 | |
| 2P7216 | 35 ELBOW | 1 | |
| 3E7402 | 36 CONNECTOR | 2 | |
| 3V3308 | 37 WASHER-HARD (10.2X20.5X2.5-MM THK) | 61 | |
| 4D8948 | 38 CLIP | 4 | |
| 4F7957 | 39 BOLT (1/4-20X0.875-IN) | 4 | |
| 5P0537 | 40 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5P1076 | 41 WASHER-HARD (13.5X30X4-MM THK) | 22 | |
| 5P4479 | 42 ELBOW (FLARED-LONG) | 1 | |
| 5P8245 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 6V5049 | 44 SEAL-O-RING | 4 | |
| 6V5102 | 45 SEAL-O-RING | 6 | |
| 7K9197 | 46 ELBOW | 3 | |
| 9S8750 | 47 NUT-FULL (1/4-20-THD) | 4 |
