System And Components
240-0664 BYPASS GP-EXHAUST -WASTEGATE (CHG -00 THRU -07)Type 1
Group No: 240-0664
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7G1239 | 1 SPACER (10.5X19X4.5-MM THK) | 4 | |
| 9M4594 | 2 SPACER (0.406X0.875X0.75-IN THK) | 1 | |
| 0L2070 | 3 BOLT (3/8-16X2.25-IN) | 1 | |
| 1S3584 | 4 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 3S2713 | 5 NUT-FULL (3/8-24-THD) | 2 | |
| 3W2647 | 6 SPACER (13.5X30X10-MM THK) | 1 | |
| 4D8532 | 7 LEVER | 2 | |
| 4F2753 | 8 LOCKNUT | 1 | |
| 4P0394 | 9 LEVER | 1 | |
| 5H2532 | 10 KEY-WOODRUFF | 3 | |
| 5L3291 | 11 BEARING AS-BALL | 2 | |
| 5P9960 | 12 BOLT (1/4-20X0.75-IN) | 2 | |
| 6V1943 | 13 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN) | 2 | |
| 6V6753 | 14 BOLT-HIGH TEMPERATURE (3/8-16X1.375-IN) | 1 | |
| 7E0701 | 15 GASKET | 4 | |
| 7L6443 | 16 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN) | 24 | |
| 8C7315 | 17 ROD END | 1 | |
| 8C7321 | 18 ROD END | 1 | |
| 8C8589 | 19 BOLT-HIGH TEMPERATURE (1/2-13X2.25-IN) | 12 | |
| 8H3390 | 20 NUT-FULL (1-1/2-12-THD) | 1 | |
| 8M2295 | 21 BOLT (3/8-16X1.625-IN) | 2 | |
| 0387444 | 22 ROD | 1 | |
| 1021694 | 23 PLATE | 1 | |
| 1023457 | 24 COVER | 1 | |
| 1026309 | 25 WASHER-THRUST | 1 | |
| 1026311 | 26 STOP | 1 | |
| 1108314 | 27 WASHER (10.3X18.3X2.66-MM THK) | 52 | |
| 1195931 | 28 SPACER | 1 | |
| 1338501 | 29 COVER AS | 1 | |
| 1440605 | 30 ADAPTER-EXHAUST | 1 | |
| 1440606 | 31 ELBOW-EXHAUST | 1 | |
| 1440621 | 32 GASKET | 1 | |
| 1450039 | 33 BRACKET AS | 1 | |
| 1450040 | 34 BRACKET AS | 1 | |
| 1450041 | 35 ROD | 1 | |
| 1450043 | 36 SHAFT | 1 | |
| 1450225 | 37 BRACKET AS | 1 | |
| 5506477 | 38 SHAFT-WASTEGATE | 1 | |
| 1468381 | 39 HOUSING AS (WASTEGATE) | 1 | |
| 1195929 | 39A BUSHING | 2 | |
| 1763583 | 40 GUARD | 2 | |
| 1763587 | 41 CLEVIS | 1 | |
| 1841613 | 42 ELBOW-EXHAUST | 1 | |
| 1845290 | 43 GASKET | 1 | |
| 1937879 | 44 BOOT | 1 | |
| 2118175 | 45 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC) | 1 | |
| 2224718 | 46 BELLOWS AS | 1 | |
| 1653931 | 47 BOLT (3/8-16X1.75-IN) | 5 | |
| 0S1587 | 48 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 49 BOLT (3/8-16X1.25-IN) | 12 | |
| 0S1590 | 50 BOLT (3/8-16X2-IN) | 1 | |
| 1653929 | 51 BOLT (3/8-16X1.5-IN) | 4 | |
| 0L1352 | 52 BOLT (3/8-16X3.25-IN) | 4 | |
| 1190746 | 53 PLUG-PIPE | 4 | |
| 1F7958 | 54 NUT-FULL (1/2-13-THD) | 14 | |
| 2253769 | 55 ROD END | 1 | |
| 2253770 | 56 ROD END | 1 | |
| 2N2766 | 57 LOCKNUT (3/8-16-THD) | 24 | |
| 3V3308 | 58 WASHER-HARD (10.2X20.5X2.5-MM THK) | 44 | |
| 3H7654 | 59 WASHER-HARD (13.5X22.5X3-MM THK) | 23 | |
| 8M9024 | 61 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9S8752 | 62 NUT-FULL (3/8-16-THD) | 17 | |
| 5P8245 | 63 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 3512247 | 64 BOLT (3/8-16X1.5-IN) | 4 |
