System And Components
150-7931 SHUTOFF GP-AIR (CHG -00, -01)8 INCH
Group No: 150-7931
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1950988 | 1 KNOB | 1 | |
| 1488136 | 2 SEAL-O-RING | 1 | |
| 1507897 | 3 SCREW (ALIGNMENT) | 1 | |
| 1507898 | 4 CAP-SUPPORT | 1 | |
| 1507899 | 5 RING-RETAINING | 2 | |
| 1507900 | 6 INDICATOR (POSITION PIN) | 1 | |
| 1507901 | 7 DRIVE-HEX SOCKET | 1 | |
| 1507902 | 8 PLATE-STOP | 1 | |
| 1507903 | 9 CAP | 1 | |
| 1507904 | 10 CLEVIS | 1 | |
| 1507905 | 11 SPRING | 1 | |
| 1507906 | 12 PIN | 1 | |
| 1507907 | 13 GASKET | 1 | |
| 1507909 | 14 RING-RETAINING | 1 | |
| 1507910 | 15 PLATE-END | 1 | |
| 1507911 | 16 SETSCREW | 2 | |
| 1507912 | 17 BUMPER | 2 | |
| 1507913 | 18 SUPPORT | 1 | |
| 1507914 | 19 SLEEVE | 1 | |
| 1507915 | 20 RING-RETAINING | 1 | |
| 1507916 | 21 WIPER | 1 | |
| 1507917 | 22 SPRING (SPINDLE) | 1 | |
| 1507918 | 23 CUP | 1 | |
| 1507919 | 24 GUIDE | 1 | |
| 1507920 | 25 SPINDLE | 1 | |
| 1507921 | 26 SPRING (COMPRESSION) | 1 | |
| 1507922 | 27 RETAINER-SPRING | 1 | |
| 1507923 | 28 SPACER | 1 | |
| 1507924 | 29 SHAFT-OPERATING | 1 | |
| 1507926 | 30 PADDLE AS | 1 | |
| 1507927 | 31 COVER | 1 | |
| 1507930 | 32 BODY | 1 | |
| 1508700 | 33 SEAL-O-RING | 2 | |
| 1508701 | 34 SEAL-O-RING | 1 | |
| 1508698 | 35 SEAL-O-RING | 1 | |
| 1508699 | 36 SEAL-O-RING | 1 | |
| 8H0707 | 37 BOLT (1/4-20X1-IN) | 2 | |
| 5J5314 | 38 BOLT (5/16-18X1.5-IN) | 8 | |
| 9M1974 | 39 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 1803953 | 40 BUSHING | 1 | |
| 1803954 | 41 BOLT | 1 | |
| 8H3127 | 42 BOLT (1/4-20X0.75-IN) | 2 |
