System And Components
235-5195 PANEL GP-INSTRUMENT -CUSTOMER INTERFACE (CHG -03 THRU -05)PART OF 235-5200 MOUNTING GP-INSTRUMENT
Group No: 235-5195
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W5972 | 1 KNOB | 1 | |
| 7C4550 | 2 SEAL (ROTATING SHAFT) | 1 | |
| 8C6024 | 3 SEAL-CONNECTOR | 1 | |
| 8C6354 | 4 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8D1429 | 5 LAMP (24-VOLT)(CLEAR) | 4 | |
| 8D2676 | 6 SWITCH AS-TOGGLE (SINGLE POLE)(CONTROL SELECT) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 9D2867 | 7 LENS-AMBER | 2 | |
| 9D3127 | 8 BASE AS-INDICATOR LIGHT | 4 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 9D9161 | 9 LENS-GREEN | 2 | |
| 9X9591 | 10 CONVERTER GP-ELECTRICAL (PULSE WIDTH MODULATED) | 1 | |
| 9Y2921 | 11 RELAY (24-VOLT) | 2 | |
| 1141142 | 12 CIRCUIT BREAKER AS (10-AMPERE) | 3 | |
| 1230316 | 13 DIODE AS | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1229458 | 14 POTENTIOMETER (1000-OHM)(ENGINE SPEED) | 1 | |
| 1281820 | 15 BRACKET | 1 | |
| 1319130 | 16 END-BRACKET | 2 | |
| 1342540 | 17 RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1798907 | 18 BLOCK-TERMINAL (400-VOLT, 16-AMPERE) | 9 | |
| 2287424 | 19 MODULE GP-DISPLAY (MESSENGER) | 1 | |
| 2352761 | 20 GASKET | 1 | |
| 2355089 | 21 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 2 | |
| 2355125 | 22 FILM-IDENTIFICATION (ENGINE SPEED CONTROL) | 1 | |
| 2355151 | 23 HARNESS AS-SWITCH (ENGINE SPEED) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1148843 | SLEEVE-PLASTIC | ||
| 2355153 | 24 HARNESS AS-WIRING (POWER) | 1 | |
| 8T8737 | PLUG-SEAL | 6 | |
| 1093039 | END-WIRE (12-GA) | 2 | |
| 2355170 | 25 CIRCUIT BREAKER AS (20-AMPERE, DOUBLE POLE) | 1 | |
| 3103483 | 26 BRACKET AS | 1 | |
| 2381271 | 27 COVER-END | 2 | |
| 2435443 | 28 FILM-IDENTIFICATION (CUSTOMER INTERFACE PANEL) | 1 | |
| 1153069 | 31 CLIP AS-CONNECTING (3-PIN) | 1 | |
| 1325789 | 32 CLIP (LADDER) | 3 | |
| 1566175 | 33 CLIP (LADDER) | 1 | |
| 2143522 | 34 SCREW-MACHINE (6-32X0.75) | 4 | |
| 4B2041 | 35 NUT (6-32-THD) | 4 | |
| 4B4863 | 36 WASHER (4.7X11X1.2-MM THK) | 6 | |
| 4P7581 | 37 CLIP (LADDER) | 1 | |
| 5S4245 | 38 SCREW-MACHINE (4-40X0.5-IN) | 4 | |
| 6B4540 | 39 NUT (4-40-THD) | 4 | |
| 6B4542 | 40 LOCKWASHER | 4 | |
| 6V4298 | 41 BOLT (M5X0.8X16-MM) | 2 | |
| 6V8801 | 42 NUT (3/8-16-THD) | 4 | |
| 7K1181 | 43 STRAP-CABLE | 4 | |
| 8C8514 | 44 SCREW-MACHINE (8-32X0.375-IN) | 2 | |
| 8T0328 | 45 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 47 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4970 | 48 BOLT (M6X1X14-MM) | 4 | |
| 9B1117 | 49 LOCKWASHER | 4 | |
| 9X8256 | 50 WASHER (6.6X12X2-MM THK) | 4 | |
| 2503485 | BOOT | 1 | |
| 1723998 | PLUG AS | 1 | |
| 3E5226 | SOCKET-CONNECTOR (12-GA TO 14-GA) | 2 | |
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 48 | |
| 8T8737 | PLUG-SEAL | 12 | |
| 3T6933 | RESISTOR | 1 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 2355183 | COVER GP-CONTROL PANEL | 1 |
