System And Components
273-4809 BOX GP-JUNCTION (CHG -00 THRU -04)
Group No: 273-4809
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2K4436 | 1 SHIM (1/32-IN THK) | 1 | |
| 7G7917 | 2 PLUG-SEAL | 5 | |
| 8D1429 | 3 LAMP (24-VOLT) | 4 | |
| 9X6856 | 4 PIN-CONNECTOR (16-GA TO 18-GA) | 32 | |
| 9D2867 | 5 LENS-AMBER (PRIMARY ECM DIAGNOSTIC) | 1 | |
| 9D2867 | 5A LENS-AMBER (SECONDARY ECM DIAGNOSTIC) | 1 | |
| 9D3127 | 6 BASE AS-INDICATOR LIGHT | 4 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 9D9161 | 7 LENS-GREEN (SECONDARY ECM ACTIVE) | 1 | |
| 9D9161 | 7A LENS-GREEN (SECONDARY ECM READY) | 1 | |
| 9G3695 | 8 PLUG-SEAL | 2 | |
| 9X9591 | 9 CONVERTER GP-ELECTRICAL (PULSE WIDTH MODULATED) | 1 | |
| 9X9675 | 10 BRACKET-END | 6 | |
| 9Y2921 | 11 RELAY (24-VOLT) | 4 | |
| 1093038 | 12 END-WIRE (16-GA) | 67 | |
| 1141142 | 13 CIRCUIT BREAKER AS (10-AMPERE) | 3 | |
| 1259969 | 14 RAIL (PERFORATED) | 3 | |
| 9X3402 | 15 SOCKET-CONNECTOR (16-GA TO 18-GA) | 7 | |
| 1666162 | 16 DUCT-WIRE | 2 | |
| 1666165 | 17 DUCT-WIRE | 2 | |
| 1798907 | 18 BLOCK-TERMINAL (400-VOLT, 16-AMPERE) | 9 | |
| 2045568 | 19 BRIDGE (5-POSITION) | 1 | |
| 2250549 | 20 BRIDGE (10-POSITION) | 2 | |
| 2250906 | 21 BRIDGE (2-POSITION) | 5 | |
| 2250907 | 22 BRIDGE (3-POSITION) | 2 | |
| 2250908 | 23 BRIDGE (4-POSITION) | 2 | |
| 2339224 | 24 RECEPTACLE-CONNECTOR (85-PIN) | 1 | |
| 2339227 | 25 SOCKET-CONNECTOR (16-GA TO 20-GA) | 28 | |
| 2339517 | 26 GASKET | 1 | |
| 2352761 | 27 GASKET | 1 | |
| 2355170 | 28 CIRCUIT BREAKER AS (20-AMPERE, DOUBLE POLE) | 1 | |
| 2381271 | 29 COVER-END | 2 | |
| 2435443 | 30 FILM-IDENTIFICATION (CUSTOMER INTERFACE PANEL) | 1 | |
| 2524943 | 31 COVER-END | 2 | |
| 2524949 | 32 BLOCK-TERMINAL (DOUBLE) | 245 | |
| 2734810 | 33 PLATE AS | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 7 | |
| 2734811 | 34 HARNESS AS-BOX | 1 | |
| 3E5519 | PLUG AS-CONNECTOR (5-PIN) | 4 | |
| 9X1056 | TERMINAL-RECEPTACLE (14-GA TO 16-GA) | 18 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1093038 | END-WIRE (16-GA) | 36 | |
| 1093039 | END-WIRE (12-GA) | 10 | |
| 1108714 | END-WIRE (18-GA) | 3 | |
| 1127497 | END-WIRE (14-GA) | 5 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(26-CM) | ||
| 1230316 | DIODE AS | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 5P2766 | TERMINAL-RING (18-GA TO 22-GA, NO. 6 SCREW) | 6 | |
| 5P4571 | TERMINAL-BLADE (14-GA TO 16-GA) | 8 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1552272 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2780447 | 35 ENCLOSURE AS | 1 | |
| 4V7412 | BOSS (3/8-16-THD) | 1 | |
| 1440426 | PANEL | 1 | |
| 1325789 | 36 CLIP (LADDER) | 1 | |
| 1H4393 | 37 LOCKWASHER | 34 | |
| 2606714 | 38 SCREW-PAN HEAD (M4X0.7X12-MM) | 11 | |
| 4B4863 | 39 WASHER (4.7X11X1.2-MM THK) | 41 | |
| 5C8312 | 40 NUT (M4X0.7-THD) | 4 | |
| 5P8167 | 41 BOLT (3/8-16X0.625-IN) | 1 | |
| 6B4540 | 42 NUT (4-40-THD) | 4 | |
| 6B4542 | 43 LOCKWASHER | 8 | |
| 6V2480 | 44 SCREW (4-40X0.5-IN) | 4 | |
| 6V5217 | 45 BOLT (M8X1.25X20-MM) | 4 | |
| 7K1181 | 46 STRAP-CABLE | 16 | |
| 7S1197 | 47 SCREW-MACHINE (8-32X0.5-IN) | 34 | |
| 8C7508 | 48 LOCKWASHER | 7 | |
| 8C9660 | 49 WASHER (4.6X7.9X0.8-MM THK) | 8 | |
| 8N1513 | 50 RECEPTACLE AS-CONNECTOR (37-PIN) | 1 | |
| 8N1522 | NUT (2-1/4-16-THD) | 1 | |
| 8N1523 | 51 LOCKWASHER | 1 | |
| 8T4896 | 52 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9M1974 | 53 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9W1951 | 54 RECEPTACLE AS-CONNECTOR (9-PIN) | 1 | |
| 8T7875 | 56 WIRE-ELECTRICAL (16-GA, BLACK)(1-CM) | ||
| 1440436 | 57 MARKER (TERMINAL) | 50 | |
| 1833192 | 58 SEAL AS (CONDUIT HOLE) | 1 | |
| 2339217 | CONNECTOR (85-PIN) | 1 | |
| 2339226 | PIN-CONNECTOR (16-GA TO 20-GA) | 85 | |
| 8T8737 | PLUG-SEAL | 85 |
