System And Components
1G-5858 LINES GP-HYDROSTATICS/N 7PJ1-UP
Group No: 1G-5858
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0870491 | 1 ADAPTER | 1 | |
| 8S7169 | 2 COUPLING | 1 | |
| 6R2051 | 3 SLEEVE | ||
| 4J5477 | 4 SEAL-O-RING | 5 | |
| 1G7966 | 5 HOSE AS | 1 | |
| 6V8398 | 6 SEAL-O-RING | 12 | |
| 1G7844 | 7 HOSE AS | 1 | |
| 0870158 | 8 HOSE AS | 1 | |
| 6V9746 | 9 SEAL-O-RING | 20 | |
| 8T8899 | 10 ELBOW | 2 | |
| 6V8988 | 11 ELBOW | 1 | |
| 6V9169 | 12 NUT (13/16-16-THD) | 1 | |
| 6V8990 | 13 ELBOW | 2 | |
| 2P1293 | 14 LOCKNUT (1-3/16-12-THD)(1 13/16-12THD) | 2 | |
| 6V8986 | 15 ELBOW | 1 | |
| 2P1279 | 16 LOCKNUT (9/16-18-THD) | 1 | |
| 1G7839 | 17 HOSE AS | 1 | |
| 3K0360 | 18 SEAL-O-RING | 2 | |
| 6V8634 | 19 CONNECTOR | 1 | |
| 6V8397 | 20 SEAL-O-RING | 5 | |
| 9S4185 | 21 PLUG (3/4-16-THD)(3/4X 16 THD) | 1 | |
| 6V9850 | 22 ELBOW (90 DEGREE-11/16-16THD) | 1 | |
| 1G7963 | 23 HOSE AS | 1 | |
| 6V9808 | 24 UNION | 1 | |
| 1P4577 | 25 FLANGE-HALF | 16 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 32 | |
| 3B1915 | 27 BOLT (3/8-16X1.375-IN) | 24 | |
| 1G7836 | 28 HOSE AS | 1 | |
| 1G7832 | 29 HOSE AS | 1 | |
| 6V8638 | 30 CONNECTOR | 1 | |
| 2M9780 | 31 SEAL-O-RING | 3 | |
| 4J0520 | 32 SEAL-O-RING | 8 | |
| 6V8647 | 33 CONNECTOR | 1 | |
| 3J7354 | 34 SEAL-O-RING | 2 | |
| 1G7835 | 35 HOSE AS | 3 | |
| 6V9807 | 36 UNION | 1 | |
| 1G7010 | 37 TUBE AS | 1 | |
| 1G7009 | 38 TUBE AS | 1 | |
| 1G7016 | 39 TUBE AS | 1 | |
| 1G7011 | 40 TUBE AS | 1 | |
| 1G7473 | 41 TUBE AS | 1 | |
| 1G7475 | 42 TUBE AS | 1 | |
| 1G7474 | 43 TUBE AS | 1 | |
| 1G7479 | 44 TUBE AS | 1 | |
| 1G7843 | 45 HOSE AS | 1 | |
| 5P2955 | 46 BOLT (5/16-18X2.5-IN) | 1 | |
| 6V8789 | 47 TEE | 2 | |
| 7R7955 | 48 PLATE (SLOTTED) | 2 | |
| 4L6459 | 49 BOLT (3/8-16X2.5-IN) | 4 | |
| 1017938 | 50 CLAMP-HALF | 4 | |
| 0869299 | 51 BAR | 5 | |
| 7R7906 | 52 CLAMP | 2 | |
| 6V8628 | 53 ELBOW | 1 | |
| 1G8362 | 54 ELBOW | 1 | |
| 9R3452 | 55 HOSE AS | 1 | |
| 6V9840 | 56 TEE-SWIVEL | 2 | |
| 1G7838 | 57 HOSE AS | 1 | |
| 4L9337 | 58 BOLT (3/8-16X1.5-IN) | 2 | |
| 7V5626 | 59 CLAMP | 2 | |
| 6W0210 | 60 BOLT (5/16-18X1.5-IN) | 9 | |
| 1G7845 | 61 HOSE AS | 1 | |
| 1G8351 | 62 ADAPTER-REDUCER | 2 | |
| 1G7846 | 63 HOSE AS | 1 | |
| 1G7837 | 64 HOSE AS | 1 | |
| 1G8352 | 65 BRACKET AS | 3 | |
| 4V0611 | 66 CLAMP | 18 | |
| 1G7489 | 67 TUBE AS | 1 | |
| 8T1012 | 68 TEE-FACE SEAL | 2 | |
| 7V6089 | 69 CLAMP | 10 | |
| 5P2675 | 70 BOLT (1/4-20X1.75-IN) | 10 | |
| 7V6234 | 71 PLATE | 1 | |
| 7R7987 | 72 HOSE AS | 1 | |
| 1G7833 | 73 HOSE AS | 1 | |
| 1G7831 | 74 HOSE AS | 1 | |
| 1G7834 | 75 HOSE AS | 1 | |
| 1G7523 | 76 TUBE AS | 1 | |
| 1G7524 | 77 TUBE AS | 1 | |
| 5K9090 | 78 SEAL-O-RING | 9 | |
| 9B7237 | 79 BOLT (3/8-16X1.25-IN) | 2 | |
| 4M5282 | 80 BOLT (1/4-20X1.5-IN) | 8 | |
| 7V5628 | 81 PLATE (TOP) | 12 | |
| 7R7907 | 82 CLAMP | 2 | |
| 7R7957 | 83 NUT | 28 | |
| 8V5718 | 84 CLAMP | 2 | |
| 7R7964 | 85 PLATE | 17 | |
| 8V5719 | 86 BOLT (5/16-18X2-IN) | 1 | |
| 7R7938 | 87 CLAMP-PIPE | 2 | |
| 7R7965 | 88 NUT | 10 | |
| 7X0440 | 89 BOLT (5/16-18X1.75-IN) | 1 | |
| 4V0612 | 90 PLATE | 1 | |
| 7X0343 | 91 BOLT (5/8-11X1.25-IN) | 6 | |
| 0869286 | 92 CLAMP | 18 | |
| 7R7951 | 93 PLATE | 5 | |
| 7X0264 | 94 BOLT (1/4-20X2.5-IN) | 12 | |
| 8T4122 | 95 WASHER-HARD (17X32X3.5-MM THK) | 6 | |
| 7R7908 | 96 CLAMP | 6 | |
| 7R7960 | 97 BOLT (1/4-20X2-IN) | 6 | |
| 0869300 | 98 BAR | 2 | |
| 4V0939 | 99 BOLT (5/16-18X1.73-IN) | 9 | |
| 7R7954 | 100 PLATE | 2 | |
| 7R7959 | 101 BOLT-SPECIAL (1/4-20X1.12-IN) | 4 | |
| 7R7940 | 102 CLAMP | 16 |
