System And Components
1G-7936 LINES GP-HYDRAULICS/N 3TK102-112
Group No: 1G-7936
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0868656 | 1 NUT | 6 | |
| 6R2678 | 2 CLAMP | 2 | |
| 7R7952 | 3 COVER | 1 | |
| 7X0265 | 4 BOLT (1/4-20X2.75-IN) | 2 | |
| 7R7908 | 5 CLAMP | 2 | |
| 7V5628 | 6 PLATE | 1 | |
| 4M5282 | 7 BOLT (1/4-20X1.5-IN) | 2 | |
| 7R7951 | 8 PLATE | 1 | |
| 7X0264 | 9 BOLT (1/4-20X2.5-IN) | 2 | |
| 7R7939 | 10 CLAMP-PIPE | 2 | |
| 8T1686 | 11 ADAPTER-ELBOW | 1 | |
| 8C8989 | 12 ELBOW | 1 | |
| 6V8398 | 13 SEAL-O-RING | 9 | |
| 3K0360 | 14 SEAL-O-RING | 3 | |
| 6V9169 | 15 NUT (13/16-16-THD) | 2 | |
| 6V8981 | 16 ELBOW | 1 | |
| 6V8994 | 17 UNION (STRAIGHT) | 1 | |
| 6V9168 | 18 NUT (11/16-16-THD) | 2 | |
| 6V8397 | 19 SEAL-O-RING | 5 | |
| 4J5477 | 20 SEAL-O-RING | 4 | |
| 6V8993 | 21 UNION | 1 | |
| 1F8488 | 22 BREATHER AS | 1 | |
| 2P1279 | 23 LOCKNUT (9/16-18-THD) | 1 | |
| 7J8611 | 24 ELBOW-PIPE | 1 | |
| 7X5331 | 25 ELBOW | 1 | |
| 1022134 | 26 TEE-BULKHEAD | 1 | |
| 6V9850 | 27 ELBOW | 1 | |
| 6V9851 | 28 ELBOW | 1 | |
| 8T6895 | 29 TEE-UNION | 1 | |
| 1019217 | 30 HOSE AS | 1 | |
| 1G7830 | 31 HOSE AS | 1 | |
| 1019218 | 32 HOSE AS | 1 | |
| 2T2265 | 33 HOSE AS | 1 | |
| 1021744 | 34 HOSE AS | 1 | |
| 1021743 | 35 HOSE AS | 1 | |
| 1021748 | 36 HOSE AS | 1 | |
| 1019221 | 37 HOSE AS | 1 | |
| 1019220 | 38 HOSE AS | 1 | |
| 1019219 | 39 HOSE AS | 1 | |
| 1019948 | 40 HOSE AS | 1 | |
| 5G8290 | 41 HOSE AS | 1 | |
| 1019222 | 42 HOSE AS | 1 | |
| 4E5137 | 43 HOSE AS | 1 | |
| 1021742 | 44 HOSE AS | 1 | |
| 8T0077 | 45 CONNECTOR | 2 | |
| 1G7840 | 46 HOSE AS | 1 | |
| 3B8490 | 47 FITTING-GREASE (1/4-18 PTF) | 1 | |
| 0870491 | 48 ADAPTER | 1 | |
| 1022133 | 49 ELBOW | 1 | |
| 4J0522 | 50 SEAL-O-RING | 2 | |
| 6V8400 | 51 SEAL-O-RING | 1 | |
| 6V8637 | 52 CONNECTOR | 1 | |
| 6V9846 | 53 TEE | 1 | |
| 6V8941 | 54 REDUCER | 1 | |
| 6V8556 | 55 NUT (1-3/16-12-THD) | 1 | |
| 3D2824 | 56 SEAL-O-RING | 4 | |
| 6V9746 | 57 SEAL-O-RING | 6 | |
| 6V8397 | 58 SEAL-O-RING | 4 | |
| 4J0524 | 59 SEAL-O-RING | 1 | |
| 5P8245 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 0S1587 | 61 BOLT (1/2-13X1.75-IN) | 8 | |
| 1P4579 | 62 FLANGE-HALF | 2 | |
| 1P4578 | 63 FLANGE-HALF | 2 | |
| 0T0772 | 64 BOLT (7/16-14X1.5-IN) | 4 | |
| 5P8244 | 65 WASHER-HARD (12X22.5X2.5-MM THK) | 4 | |
| 3J1907 | 66 SEAL-O-RING | 1 | |
| 1029291 | 67 ELBOW | 1 | |
| 6V9007 | 68 ELBOW | 2 | |
| 6V8633 | 69 CONNECTOR | 1 | |
| 6V8639 | 70 CONNECTOR | 1 | |
| 6V9874 | 71 CONNECTOR (STRAIGHT) | 1 | |
| 1P4582 | 72 FLANGE-HALF | 2 | |
| 4J0527 | 73 SEAL-O-RING | 1 | |
| 3J7354 | 74 SEAL-O-RING | 1 | |
| 8C8988 | 75 ELBOW | 1 | |
| 6V9872 | 76 CONNECTOR | 1 | |
| 3K0360 | 77 SEAL-O-RING | 4 | |
| 6V8398 | 78 SEAL-O-RING | 4 | |
| 8T0077 | 79 CONNECTOR | 2 |
