System And Components
6T-3388 HEATER GP-CABS/N 8RC4000-UP; 1DD4000-UP
Group No: 6T-3388
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6T1912 | 1 CABLE AS-TORSION | 1 | |
| 9L9596 | SETSCREW-SOCKET (8-32X0.25-IN) | ||
| 7X0848 | NUT-BULKHEAD (3/8-32-THD) | 2 | |
| 9F5644 | LOCKWASHER | 1 | |
| 2V0099 | 2 KNOB-CONTROL | 1 | |
| 7G8699 | 3 VALVE-WATER | 1 | |
| 6T3983 | 4 BRACKET | 1 | |
| 8C3227 | 5 SCREW-MACHINE (10-32X0.44-IN) | 2 | |
| 4B4274 | 6 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 0S1614 | 7 BOLT (1/4-20X0.5-IN) | 2 | |
| 5P0537 | 8 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 3T9472 | 9 COIL-HEATER | 1 | |
| 6T5617 | 10 PLATE | 1 | |
| 0L1351 | 11 BOLT (3/8-16X0.875-IN) | 4 | |
| 5P1075 | 12 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 5P0767 | 13 HOSE (15CM) | ||
| 5D1026 | 14 CLAMP-BAND | 2 | |
| 5P5643 | 15 SEAL | ||
| 5P5684 | 16 SEAL | ||
| 1D4717 | 17 NUT (3/8-16-THD) | 1 | |
| 9F8125 | 18 LOCKWASHER | 2 |
