7P-5719 SEAT GP-ADJUSTABLES/N 86G3000-UP

Group No: 7P-5719
Part NumberPart NameQty
5P25661 BOLT (1/2-13X1.5-IN)2
4V8586SPACER (13.92X32.25X4.22-MM THK)2
4V85942 CUSHION AS-SEAT1
4V85793 CLIP1
4V85994 ADJUSTER GP-SEAT1
4V78965 CAP1
4V78656 CAP1
5S73797 BOLT (3/8-16X0.875-IN)2
4V86058 SPACER (3-MM THK)2
4B42789 WASHER (10.2X20.5X1.6-MM THK)4
4V825910 CUSHION AS-BACKREST1
5V1496RETAINER19
5P795711 LANYARD1
6K3273RIVET-POP1
6K3274PLATE-RIVET1
4V857912 CLIP1
5P568413 SEAL
4V790214 PAN AS1
4V7903PAN1
5V1719SNAP6
0337291RIVET-POP14
4V858515 LATCH1
5V0017RIVET-FLAT HEAD9
4V858116 CLIP1
4V802317 COVER1
5V158418 NUT-CLINCH4
4V860419 CABLE2
2K497320 LOCKNUT (3/8-16-THD)6
4V825621 SPRING2
4V803122 SPRING2
5M306223 BOLT (3/8-16X0.75-IN)2
4V803324 BAR1
7V372825 LATCH AS1
4V8035CAP1
4V803426 BOLT (1/2-13X1.47-IN)2
5V1499NUT-CLINCH (1/2-13-THD)2
4B4281WASHER (16.8X33X2.5-MM THK)2
4B4280WASHER (13.5X27X2.5-MM THK)2
5V149827 LOCKNUT (3/8-16-THD)2
0307571BOLT (3/8-16X1-IN)2
4V790428 PLATE AS (RH)1
4V7908PLATE AS (LH)1
4V802929 BRACKET AS (RH)1
4V8026BRACKET AS (LH)1
1A203630 DOWEL1
5P7958SLEEVE-CABLE SPLICE1
