System And Components
8X-9837 TANK GP-FUELS/N 7KR219-UP
Group No: 8X-9837
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9P7121 | 1 STRAINER-FUEL | 1 | |
| 8T9392 | 2 BOLT (1/2-13X7.5-IN) | 4 | |
| 5P1076 | 3 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 1K6872 | 4 LOCKNUT (1/2-13-THD) | 4 | |
| 5T4630 | 5 MOUNT | 2 | |
| 5P8502 | 6 PADLOCK GP (FUEL TANK) | 1 | |
| 5P8500 | KEY (FUEL TANK) | 1 | |
| 8Y6364 | SLEEVE | 1 | |
| 5T4639 | 7 CLAMP | 4 | |
| 1034855 | 8 TANK AS-FUEL | 1 | |
| 8F9836 | BOSS (3/8-16-THD) | 1 | |
| 8X1251 | TUBE AS | 1 | |
| 1P4582 | 9 FLANGE-HALF | 2 | |
| 7X3325 | BOLT-LOCKING (1/2-13-THD) | 4 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 7T2036 | 10 CAP AS-FILLER (FUEL) | 1 | |
| 3F4134 | 11 BAFFLE (FUEL TANK FILL CAP) | 1 | |
| 4B1663 | 12 FILTER ELEMENT-FUEL (FUEL CAP) | 1 | |
| 4B5423 | 13 GASKET | 1 | |
| 4B5949 | 14 FILTER ELEMENT-FUEL (FUEL CAP)(FUEL) | 1 | |
| 7B2002 | 15 WASHER (10.2X44.5X3-MM THK) | 1 | |
| 7T2009 | 16 VALVE AS | 1 | |
| 7T2037 | 17 GASKET (FUEL CAP) | 1 | |
| 8P0408 | 18 CAP-FILLER (FUEL TANK) | 1 | |
| 7X0350 | 19 BOLT (5/8-11X3.5-IN) | 2 | |
| 8T4122 | 20 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 7D0734 | 21 WASHER (0.656X2.38X0.25-IN THK)(2.5MM THK) | 2 | |
| 8G0841 | 22 MOUNT AS | 2 | |
| 3K2889 | 23 LOCKNUT (5/8-11-THD) | 2 | |
| 5P5684 | 24 SEAL |
