System And Components
138-4839 BLOWER GP-CABS/N 4MS1-UP; 5JS1-UP
Group No: 138-4839
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C3756 | 1 FILM-IDENTIFICATION (AIR CONDITIONER) | 1 | |
| 1003143 | 2 PLATE-ORIFICE | 2 | |
| 2M1444 | 3 SCREW-TAPPING (8-18X0.3-IN) | 6 | |
| 1942019 | 4 HARNESS AS (CAB HEATER) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1779648 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 4B1219 | 5 SCREW-MACHINE (6-32X0.375-IN) | 3 | |
| 6V8368 | 6 NUT (6-32-THD) | 3 | |
| 3L8187 | 7 LOCKWASHER | 3 | |
| 1003426 | 8 WHEEL AS-BLOWER | 2 | |
| 1084634 | 9 HOUSING AS | 1 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8C4586 | 10 CLAMP | 2 | |
| 6V7728 | 11 BOLT (M6X1X45-MM) | 1 | |
| 8T4205 | 12 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 1293178 | 13 LOCKNUT (M6X1-THD) | 2 | |
| 5P5684 | 14 SEAL (0.13M) | 2 | |
| 1084639 | 15 GASKET | 2 | |
| 1084641 | 16 GASKET | 1 | |
| 7X0490 | 17 BOLT (M6X1X200-MM) | 1 | |
| 6V1668 | 18 WASHER (6.5X29.1X3-MM THK) | 2 | |
| 7T3828 | 19 RESISTOR | 1 | |
| 7X6021 | 20 BRACKET AS | 1 | |
| 1741490 | 21 MOTOR AS-ELECTRIC | 1 | |
| 7T0093 | PIN-CONNECTOR (12-GA TO 14-GA) | 2 | |
| 1779645 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5P5908 | 22 SEAL (0.11-M) | 1 | |
| 5P5684 | 23 SEAL (0.07-M) | 2 |
