System And Components
156-1014 LINES GP-WATER (CHG -00, -01, -01D1, -01D2, -01D3, -01D4-01D5 THRU -03, -03D1, -03D2, -03D3, -03D4)COMBINED
Group No: 156-1014
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1588 | 1 BOLT (3/8-16X1.25-IN) | 12 | |
| 2A4639 | 2 BOLT (3/8-16X1.625-IN) | 8 | |
| 0S1594 | 3 BOLT (3/8-16X1-IN) | 8 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 6 | |
| 3S9643 | 5 SEAL-LIP TYPE | 6 | |
| 3V3308 | 6 WASHER-HARD (10.2X20.5X2.5-MM THK) | 16 | |
| 4P9224 | 7 COVER | 1 | |
| 5M1719 | 8 STUD-TAPERLOCK (3/8-16X1.87-IN) | 8 | |
| 5P6619 | 9 SEAL-O-RING | 3 | |
| 1983427 | 10 REGULATOR-WATER TEMPERATURE (95-DEG C) | 6 | |
| 6V3250 | 11 SEAL-O-RING | 1 | |
| 7W2022 | 12 HOUSING | 1 | |
| 7W3269 | 13 GASKET | 5 | |
| 7W3271 | 14 COVER | 1 | |
| 7W3272 | 15 GASKET | 1 | |
| 7W5767 | 16 HOUSING-REGULATOR | 1 | |
| 7W5843 | 17 ELBOW | 1 | |
| 7W6408 | 18 COVER | 1 | |
| 7W6940 | 19 GASKET | 1 | |
| 7W9755 | 20 ORIFICE | 1 | |
| 8T6762 | 21 PLUG-PIPE (1/2-14-THD) | 3 | |
| 8T6765 | 22 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S4191 | 23 PLUG (9/16-18-THD) | 1 | |
| 9S8752 | 24 NUT-FULL (3/8-16-THD) | 8 | |
| 1021403 | 25 FLANGE | 2 | |
| 1203954 | 26 TUBE AS | 1 | |
| 1381269 | 27 SPACER | 4 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 |
