System And Components
126-4112 LINES GP-AIR (CHG -01 THRU -05)STARTING MOTOR
Group No: 126-4112
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1587 | 1 BOLT (1/2-13X1.75-IN) | 12 | |
| 1H2815 | 2 NIPPLE-PIPE | 3 | |
| 1H7722 | 3 FITTING (1-1/2-11-1/2 NPT) | 1 | |
| 2W2945 | 4 LUBRICATOR GP-AIR MOTOR | 2 | |
| 7W0524 | PLUG AS | 1 | |
| 7W0537 | DOME AS | 1 | |
| 7W2759 | BOWL AS | 1 | |
| 7W2760 | KIT-SEAL (AIR MOTOR) | 1 | |
| 3B6492 | 5 COUPLING-PIPE (1-1/2-11-1/2 NPT THD) | 2 | |
| 3L1258 | 6 NIPPLE-PIPE | 4 | |
| 4P4113 | 7 HOSE AS | 1 | |
| 4W2245 | 8 VALVE-SHUTOFF | 2 | |
| 5H0255 | 9 BOSS | 4 | |
| 5L2534 | 10 U-BOLT | 2 | |
| 5N7131 | 11 FLANGE | 3 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 6B7280 | 13 ADAPTER | 1 | |
| 6F7701 | 14 TEE-PIPE | 5 | |
| 6F7732 | 15 BUSHING-REDUCER | 1 | |
| 6F8856 | 16 ELBOW | 8 | |
| 6F8858 | 17 FITTING | 10 | |
| 6H1717 | 18 BOLT (1/2-13X1.125-IN) | 4 | |
| 6L7028 | 19 JOINT AS | 1 | |
| 9X7535 | SEAL | 2 | |
| 6V4501 | 20 NIPPLE-PIPE | 1 | |
| 6V8252 | 21 UNION-PIPE | 2 | |
| 7C0818 | 22 BRACKET | 1 | |
| 8N8451 | 23 GASKET | 3 | |
| 8T6760 | 24 PLUG-PIPE (1-1/2-11-1/2 NPT) | 1 | |
| 8T6765 | 25 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9F9747 | 26 FITTING (1-1/2 STD PIPE THD) | 2 | |
| 9L9132 | 27 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9S8752 | 28 NUT-FULL (3/8-16-THD) | 4 | |
| 1065620 | 29 CLAMP-PIPE | 3 | |
| 1778845 | 30 VALVE AS-RELAY (AIR START) | 2 | |
| 1264114 | 31 VALVE-AIR | 1 | |
| 1264115 | 32 BRACKET | 1 | |
| 1264116 | 33 NIPPLE-PIPE | 3 | |
| 1264117 | 34 NIPPLE-PIPE | 1 | |
| 1264118 | 35 NIPPLE-PIPE | 1 | |
| 1465215 | 36 STRAINER GP-AIR LINES | 2 | |
| 6F6045 | 37 NIPPLE-PIPE | 2 | |
| 1778847 | KIT-SEAL (RELAY VALVE) |
