System And Components
9Y-4252 BARRING & MOUNTING GP (CHG -00, -01, -01D1, -01D2, -01D3, -01D4, -01D5, -01D6, -01D7)
Group No: 9Y-4252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1585 | 1 BOLT (1/2-13X1.5-IN) | 4 | |
| 9Y4254 | 2 BRACKET AS | 1 | |
| 6V3538 | 3 DOWEL | 2 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 1 | |
| 1P7346 | 5 WASHER-HARD (10.2X35X6-MM THK) | 1 | |
| 5L1091 | 6 SPRING | 1 | |
| 7W0195 | 7 STEM | 1 | |
| 4W9551 | 8 RETAINER | 1 | |
| 3B8489 | 9 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 5H9573 | 10 KNOB-CHOKE | 1 | |
| 9S8748 | 11 NUT-FULL (1/4-28-THD) | 1 | |
| 7W0196 | 12 GUIDE | 1 | |
| 7W0194 | 13 GUIDE | 1 | |
| 4T4027 | 14 SPRING | 1 | |
| 9S1328 | 15 WASHER (26X41X1.6-MM THK) | 1 | |
| 6H6109 | 16 RING-SNAP | 1 | |
| 7W0193 | 17 SPACER (26.65X44X10-MM THK) | 1 | |
| 5P3456 | 18 SEAL-O-RING | 2 | |
| 9Y0539 | 19 SHAFT-BARRING | 1 | |
| 4W9549 | 20 PINION (11-TEETH) | 1 |
